JAIS 4x4 Emirati Mine-Resistant Ambush Protected (MRAP)
JAIS 4x4
Mine-Resistant Ambush Protected (MRAP)
Other
Basic Information
Name
JAIS 4x4 Emirati Mine-Resistant Ambush Protected (MRAP)
Designation
JAIS 4x4
Alternate Designation
JAIS 4x4
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
NIMR
Date of Introduction
2022
Description
The JAIS 4x4 Emirati Mine-Resistant Ambush Protected (MRAP) vehicle is utilized by the armed forces of the United Arab Emirates. It has been deployed in conflict zones and has proven effective in saving soldiers' lives due to its robust design and high level of protection. The JAIS 4x4 strikes an excellent balance between firepower, survivability, mobility, and cost, making it suitable for both modern conventional and asymmetric operations. This vehicle can be configured for various roles, including reconnaissance, patrol, utility, and ambulance services.
Ground Specifications
Crew
2
Mobility Type
Wheeled (4x4)
Engine
Diesel (336 hp)
NBC Protection
Yes
Max Speed
100.0 km/h
Range
700.0 km
System
Alternative Designation
JAIS 4x4
Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
NIMR
Configuration
4x4
Crew
2 ea
Passengers
5 ea
Payload Capacity
3,200 kg
Dimensions
Length
6,100 mm
Width
2,825 mm
Height
2,620 mm
Wheelbase
3,350 mm
Weight, Combat
20,500 kg
Automotive
Engine Name
Caterpillar
Engine Type
Diesel
Engine Power
336 kW / 450 hp
Engine Torque
1,850 Nm
Maximum Range
700 km
Maximum Speed
100 km/h
Amphibious
No
Gradient
60%
Side Slope
500 mm
Vertical Step
500 mm
Trench
1,000 mm
Fording
900 mm
Main Weapon System
Note
The roof of the JAIS 4x4 can be fitted with a range of weapon systems including one- or two-man light and medium turrets armed with weapons up to 30mm caliber. The vehicle can also be equipped with a remotely operated weapon station.
Protection
Armor
It is an MRAP vehicle (Mine Resistant Ambush Protected) that provides ballistic protection up to STANAG 4569 Level 4 (14.5×114mm AP / B32 at 200 meters with 911 m/s) and mine protection STANAG 4569 up to Level 4A/4B (10 kg of mine blast explosion under the wheels (4a) and floor (4b). The crew survivability is centered around a combat-proven "crew citadel" protection system that is very efficient against mines, IEDs (Improvised Explosive Devices), and ballistic threats.
Applique Armor
Available
NBC Protection
Yes
Smoke Equipment
Yes
Image Sources
Notes
https://edgegroupuae.com/solutions/jais-4x4; https://products-webfiles.edgegroup.ae/s3fs-public/2025-02/nimr-jais-class-en_0.pdf; https://armyrecognition.com/archives/archives-land-defense/land-defense-2021/idex-2021-nimr-jais-combat-proven-mine-resistant-ambush-protected-mrap-vehicle-made-in-uae; https://www.armadainternational.com/2024/02/world-defense-show-2024-edge-debuts-jais-mark-2-in-milestone-upgrade-of-entire-armoured-vehicle-line/
Details
Country of Origin
United Arab Emirates
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
J
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.1 m
Width
2.83 m
Height
2.62 m
Weight
20500 kg
Operators (1)
United Arab Emirates
