Boris Chilikin-Class (Project 1559V Morskoy Prostor Class) Russian Large Seagoing Tanker

Boris Chilikin-Class

Large Seagoing Tanker
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Boris Chilikin-Class (Project 1559V Morskoy Prostor Class) Russian Large Seagoing Tanker
Designation
Boris Chilikin-Class
Alternate Designation
Boris Chilikin-Class; Project 1559V Morskoy Prostor Class
Equipment Type
Large Seagoing Tanker
Manufacturer
Date of Introduction
1970
Description

Boris Chilikin-Class (Project 1559V Morskoy Prostor Class) Russian Large Seagoing Tankers a series of fleet replenishment oilers built in the 1970s for the Soviet Navy and currently in service with the Russian Navy. As the Soviet Navy began to more regularly operate in large areas of the world's oceans and because of the emergence of the Kiev-class aircraft carriers, demand for large surface supply ships increased. In 1967, the TsKB "Baltsudoproyekt" (now Baltic Shipyard) received a technical and tactical assignment for the design of Project 1559V sea oilers based on the civilian Project 1559 or Velikiy Oktyabr class. The main designers were S.N. Shumilov and Captain 2nd rank Yu. D. Makshanchikov. The oilers of this class are equipped with a device for the transfer of goods in a move by the traverse method. This allows carrying out cargo operations during significant sea waves.

Naval & Littoral Specifications
Crew 75
Beam 21.40 m
Draft 9.30 m
Variants
Boris Chilikin Commissioned: 1970 Status: Active Fleet: Black Sea Fleet
Vladimir Kolechitskiy Commissioned: 1972 Status: Decommissioned in 2012 Fleet: Pacific Fleet
Dnestr Commissioned: 1973 Status: Active Fleet: Northern Fleet
Ivan Bubnov Commissioned: 1975 Status: Active Fleet: Black Sea Fleet
Genrikh Gasanov Commissioned: 1976 Status: Decommissioned in 2012 Fleet: Northern Fleet
Boris Butoma Commissioned: 1978 Status: Active Fleet: Pacific Fleet
System
Alternative Designation Boris Chilikin-Class; Project 1559V Morskoy Prostor Class
Type Large Seagoing Tanker
Builder Baltic Shipyard (Baltiysky Zavod), St. Petersburg, Russia
Crew 75 total (all civilians)
Cargo Capacity Cargo capacity is 8,250 tons fuel oil, 2,050 tons diesel fuel, 1,000 tons jet fuel (kerosene), 450 tons fresh water, 450 tons boiler feed water, 250 tons lube oil and 220 tons dry cargo (mostly provisions).
Fuel Transfer Capability There are provisions in these ships for transferring fuels to ships on either side and astern; the early units could transfer provisions on both sides, but the later ships can only do so to starboard.
Cranes There are 2 x 3-ton electric cranes mounted towards the forcastle.
Dimensions
Length 162.30 m
Beam 21.40 m
Draft 9.30 m
Displacement, Standard 6,950 tons
Displacement, Full Load 24,460 tons
Endurance 90 days
Propulsion System
Engine Name 1 x Cegielski-Sulzer type 6 DNRN-74/160
Engine Type Diesel
Engine Power 9,600 total bhp
Range 12,000 nm at 12 knots; 10,000 nm at 16 knots
Maximum Speed 16 knots
Gun Weapon Systems
Note Originally, the ships were armed with two 57 mm AK-725 guns and two 30mm AK-630 rotary cannons, but during later operations these defensive weapons were removed.
Radar Systems
Navigation Radar 2 x Don-2 navigation radars (on Vladimir Kolechitskiy), or 2 x MR-212/201 Vaygach-U navigation radar.
Protection
Hull The class has a deadweight tonnage of 16,300 tons.
Countermeasures None
NBC Water Washdown System Yes
Details
Country of Origin Russia
Category Support Ships
Naval > Support Ships
Filter Label
B
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
162.3 m
Width
Height
Weight
Operators (1)
Russia
