A400M-180 Atlas French Transport Aircraft
A400M-180
Spotted an error? Sign in to suggest an edit.
Other
Basic Information
Name
A400M-180 Atlas French Transport Aircraft
Designation
A400M-180
Alternate Designation
—
Equipment Type
—
Manufacturer
Airbus Military / Airbus Defense and Space
Date of Introduction
2013
Description
The Airbus A400M Atlas is a European four-engine turboprop military transport aircraft. It was designed by Airbus Military (now Airbus Defense and Space) as a tactical airlifter with strategic capabilities to replace older transport aircraft, such as the Transall C-160 and the Lockheed C-130 Hercules. Along with the transport role, the A400M can perform aerial refueling and medical evacuation when fitted with appropriate equipment.
Air & Air Defense Specifications
Crew
3
Engine
Turboprop (11000 hp)
Cruise Speed
0.7 km/h
Range
5100.0 km
Variants
A400M Grizzly
Prototype
System
Alternate Designation(s)
A400M-180 Atlas
Primary Function / Type
Transport Aircraft
Manufacturer
Airbus Military / Airbus Defense and Space
Crew
3 (pilot, co-pilot and loadmaster)
Passengers/Cargo Capacity
116 troops or 9 x 88-in x 108-in pallets
Number of Engines
4
Number of Hard Points
INA
Dimensions
Length
45.10 m
Height
14.70 m
Width (Wing Span)
42.40 m
Wing Area
221.5 m sq
Wheelbase
13.30 m
Track
6.20 m
Cargo Area, Flat Floor Length
17.71 m
Cargo Area, Height
3.85 m
Cargo Area, Width
4.00 m
Cargo Area, Ramp Length
5.40 m
Cargo Area, Floor Area
92.0 m sq
Cargo Area, Gross Volume
340.0 cu m
Empty Weight
59,250 kg
Maximum Takeoff Weight
141,000 kg
Tactical Takeoff Weight
116,500 kg
Logistical Takeoff Weight
130,000 kg
Landing Weight
123,000 kg
Tactical Payload Weight
29,500 kg
Logistical Payload Weight
37,000 kg
Automotive
Engine Name
4 x TP-400 D6
Engine Type
Turboprop
Engine Power
11,000 shp each
Fuel Capacity
61,800 liters
Cruise Speed
Mach 0.72
Ceiling
12,190 m
Maximum Range
5,100 km
Ferry
8,700 km
Load Factor
3 g max
Maximum Roll Rate
30 deg/sec
Protection
Stealth Properties
None
Heat Signature Reduction
No
Add on Armor
INA
NBC Protection
INA
EW Counter Measures
INA
Chaffs/Flares
INA
Details
Country of Origin
France
Category
Fixed Wing Aircraft
Air > Fixed Wing Aircraft
Filter Label
A
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
45.1 m
Width
42.4 m
Height
14.7 m
Weight
141000 kg
Operators (14)
France
Germany
United Kingdom
South Korea
Turkey
South Africa
Spain
Belgium
Chile
Hungary
Indonesia
Kazakhstan
Luxembourg
Malaysia
