CH-YH1000 Chinese Unmanned Aerial Vehicle (UAV)

CH-YH1000

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
CH-YH1000 Chinese Unmanned Aerial Vehicle (UAV)
Designation
CH-YH1000
Alternate Designation
CH-YH1000
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Aerospace CH UAV Co Ltd
Date of Introduction
2025
Description

The CH-YH1000 Chinese Unmanned Aerial Vehicle (UAV) stands out due to its 1,000-kilogram payload capacity, a feature that makes it a key player in logistics operations, particularly in military and humanitarian contexts. The drone is designed to carry heavy loads while maintaining low energy consumption, allowing for long-duration missions. The CH-YH1000 possesses characteristics that make it suitable for a wide range of missions, including in conflict zones or regions affected by natural disasters. Its ability to take off and land on short runways and difficult terrain is a major advantage, potentially extending its use in hard-to-reach environments. The CH-YH1000 is part of a broader push to develop transport drones in China, where these technologies are viewed as innovative and cost-effective solutions for modernizing logistics capabilities. These drones can replace traditional vehicles for difficult transport missions, especially in remote regions or wartime conditions where conventional transport infrastructure may be damaged or nonexistent. China's progress in the field of transport drones highlights the growing importance of the unmanned mobility industry. The success of the CH-YH1000 could also boost the export of this technology, particularly to countries seeking robust and effective unmanned transport solutions. In order to ensure that the cargo can be conveniently and efficiently delivered to the cabin, it is equipped with an upward-flipping nose door. It is also equipped with a belly hatch, which can be used for special needs such as emergency airdrops, pesticide spraying or firefighting.

Air & Air Defense Specifications
Max Speed 200.0 km/h
Endurance 10.00 hrs
Service Ceiling 8000 m
Payload Capacity 1000 kg
System
Alternate Designation CH-YH1000
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Aerospace CH UAV Co Ltd
Payload Capacity 1,000 kg
Dimensions
Length INA
Height INA
Wingspan INA
Maximum Takeoff Weight 2,300 kg
Automotive
Engine Name INA
Engine Type INA
Engine Power INA
Maximum Speed 200 km/h
Maximum Range INA
Service Ceiling 8,000 m
Endurance 10 hours
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
C
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
2300 kg
Operators (1)
China
