MRH90 Australian Utility Helicopter

MRH90

Utility Helicopter
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
MRH90 Australian Utility Helicopter
Designation
MRH90
Alternate Designation
MRH90
Equipment Type
Utility Helicopter
Manufacturer
Date of Introduction
2016
Description

For decades the Australian military relied on the ubiquitous Bell UH-1 "Huey" helicopter line and thought (and funding) was finally given to adopt a more modern product - this became the MRH-90 "Taipan" (MRH = "Multi-Role Helicopter") based on the NHIndustries NH90 series. The NH90 serves in the medium-lift role and can undertake many mission types for military and civilian industries. Nearly 250 have been produced (2015) with service seen through the French, Italian and Finnish armies. The helicopter is an original product from NHIndustries (NHI), the helicopter arm of what was once Eurocopter - now falling under the Airbus Helicopters brand label. For the Australian military the Taipan fulfills a utility role and will serve both its Army and Navy forces. An early-batch order in 2005 called for twelve helicopters to replace UH-1 models and a 2006 follow-on order totaled 34 systems to succeed outgoing Sikorsky UH-60 "Black Hawk" and Westland "Sea King" helicopters. The Australian military plans to procure no more than 47 MRH-90s in all with four to be produced in Europe and the remainder in Australia by Airbus Helicopters subsidiary Australian Aerospace of Brisbane. Forty units are set aside for Army use and six are to be used by the Navy. While the original order was for 46 total aircraft, a renegotiated contract of 2013 yielded the Australian government one extra airframe which will be set aside for training duty. The MRH-90 has had a rocky development, forcing revisions as evaluations were being undertaken. Since 2010 the helicopter was repeatedly showing up on the Australian government's "shame list" for its many problems and delayed service entry. While first deliveries came in 2007, final examples will not be on hand until 2016 or 2017 - over ten years since the initial order was placed. For cost reasons, the Army will still be forced to use their Black Hawks until 2018. Initial Operational Capability (IOC) was finally had in 2014 by the Army with the Navy following a year later. The MRH-90 has experience issues with object ingestion in its turboshaft (Rolls-Royce) engines despite the fact that protective screens were in place (the screens were not suitable for the debris available in the Australian landscape). Additionally, windshield cracking was a constant which resulted in a special film being applied for added strength and a new installation procedure being drawn up. In 2010 a single engine failure occurred to an MRH-90 by Adelaide which caused a fleet grounding during the review process (shaft bowing was blamed). A stronger cabin floor was then ordered when it was found that the original lightweight design suffered under the stress of equipment-laden Australian infantry. Beyond other scheduled additions (rappelling equipment, door guns, etc...) it appears that the darkest days of the MRH-90 program are behind it.

Air & Air Defense Specifications
Crew 3
Engine Turboshaft (2230 hp)
Service Ceiling 6000 m
System
Alternative Designation MRH90
Type Utility Helicopter
Role - Anti-Submarine Warfare (ASW) - Anti-Ship - Transport - Medical Evacuation (MEDEVAC) - Search and Rescue (SAR) - Special Forces
Status 2016-Present
Crew 3 ea
Blades, Main Rotor 4
Blades, Tail Rotor 4 ea
Number of Engines 2 ea
Day/Night Capable Yes
All Weather Capable Yes
Dimensions
Length 16.15 m m
Main Rotor Diameter 16.3 m
Height 5.25 m
Weight, Empty 6,400 kg
Weight, Combat 10,600 kg
Automotive
Engine Name 2 x Rolls-Royce Turbomeca RTM322-01/9
Engine Type turboshaft engines
Engine Power developing 2,230 horsepower each
Cruising Range 800 km
Speed, Maximum 300 km/h
Service Ceiling 6,000 m
Rate-of-Climb 480 m/min
Fuel Capcity 1,900 kg
Main Weapon System
Note The MRH90 typically only has a door-mounted machine gun for local defense.
Protection
Cockpit Glass INA
Stealth Properties No
Heat Signature Reduction INA
Add on Armor INA
NBC Protection Yes
EW Counter Measures/CCM INA
Counter Measures (Chaff/Flares) INA
Details
Country of Origin Australia
Category Utility Helicopter
Air > Utility Helicopter
Filter Label
M
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
16.15 m
Width
Height
5.25 m
Weight
10600 kg
Operators (1)
Austria
