Dragon Runner 20 American Small Unmanned Ground Robot
Dragon Runner 20
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Dragon Runner 20 American Small Unmanned Ground Robot
Designation
Dragon Runner 20
Alternate Designation
Dragon Runner 20
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
QinetiQ North America
Date of Introduction
2005
Description
Dragon Runner 20 Small Unmanned Ground Robot Small and lightweight, yet rugged and feature-packed, the Dragon Runner 20 (DR-20) is a highly specialized and mobile robot designed to provide situational awareness, safety and support for reconnaissance, security, inspection and IED missions. The mission dictates exactly how the DR-20 will be used – making it the perfect choice for defense and security applications especially in congested urban settings. Whether it’s at a security checkpoint, deep inside a sewer or drainpipe or tasked with an EOD mission, the DR-20 supports a wide range of scenarios. At 20 pounds, the DR-20 can be hand carried by one person and easily deployed.
Ground Specifications
Max Speed
6.0 km/h
Variants
Dragon Runner 10
Dragon Runner 10
Micro Unmanned Ground Robot
The Dragon Runner 10® (DR-10) is a lightweight, expandable robot that offers protection and support to small unit, dismounted operations. Designed to provide situational awareness by ‘scouting out’ while the operator remains at safe distance, the DR-10 keeps military forces and first responders away from dangerous situations.
At approximately 10 pounds the DR-10 can be hand carried or easily transported inside a rucksack—it can even be thrown! This compact and durable robot is operated with an easy-to-use remote controller. Its robust design allows it to perform in the most challenging environments and adverse weather conditions.
Whether it’s under a car or deep inside a sewer or drainpipe, the DR-10 has the dexterity to go where personnel can’t. From unmanned, reconnaissance missions to delivering remote sensors and placing counter-IED charges, these micro robots protect people, assets and save lives.
System
Alternative Designation
Dragon Runner 20
Type
Small Unmanned Ground Robot
Manufacturer
QinetiQ North America
Crew
Unmanned ea
Communications
On-board microphone
Environmental
IP 65 rated
Cameras
Four (4) front and rear (day and night
capable); left and right (day only);
quad video display
Controller
Dragon Runner 20 wearable
controller, UC-LITE
Lift Capacity
4.5 kg
Payloads (optional)
Disruptors, manipulator arm, RSTA
cameras, two-way audio, fiber
control tether, Hazmat sensors
Dimensions
Length
89 cm
Width
40 cm
Height
54 cm
Weight
9-11.8 kg
Automotive
Engine Name
INA
Engine Type
INA
Engine Power
INA
Maximum Speed
6 Km/h
Operational Range
2,100 ft (650+m) Line-of-Sight
Endurance
3-4 hrs (mission dependent)
Protection
Hull Armor
INA
Applique Armor
INA
Details
Country of Origin
United States
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
D
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
0.89 m
Width
0.4 m
Height
0.54 m
Weight
9 kg
Operators (1)
United States
