KVD-002 Chinese Unmanned Aerial Vehicle (UAV)

KVD-002

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
KVD-002 Chinese Unmanned Aerial Vehicle (UAV)
Designation
KVD-002
Alternate Designation
KVD-002
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
China Academy of Aerospace Aerodynamics
Date of Introduction
2023
Description

The KVD-002 Chinese Unmanned Aerial Vehicle (UAV) is a next-generation platform that evolved from the proven CH-4 design. It is specifically engineered to address modern threats and support extended missions, delivering substantial information superiority on the battlefield. The KVD-002 offers the People’s Liberation Army Ground Force (PLAGF) comprehensive battlefield support through multiple advanced capabilities: • Intelligence, Surveillance, and Reconnaissance (ISR): Enables long-duration observation and reconnaissance missions; • Fire Support: Delivers direct air-to-ground strikes using precision-guided munitions; • Coordination: Assists attack helicopters in targeting, improving the operational effectiveness of helicopter units; • Airborne Early Warning: Enhances airborne early warning and supports control aircraft operations; • Command and Control: Provides advanced C4ISR (Command, Control, Communications, Computers, Intelligence, Surveillance, and Reconnaissance) capabilities to ground forces. The introduction of the KVD-002 represents a substantial expansion of the PLAGF's operational capabilities. Prior to its unveiling, the Ground Force lacked organic unmanned combat air reconnaissance and precision strike capabilities, forcing reliance on Air Force assets or coordination with other service branches. The KVD-002's 30-hour endurance combined with its strike package addresses this capability gap and supports China's overseas expansion interests through enhanced reconnaissance and precision engagement capabilities.

Air & Air Defense Specifications
Engine Heavy-Fuel Engine
Max Speed 230.0 km/h
Cruise Speed 150.0 km/h
Range 4000.0 km
Endurance 30.00 hrs
Service Ceiling 9000 m
Payload Capacity 350 kg
System
Alternate Designation KVD-002
Type Unmanned Aerial Vehicle (UAV)
Manufacturer China Academy of Aerospace Aerodynamics
Payload Capacity 350 kg
Operational Flexibility Capable of short takeoffs and landings in plateau regions, enabling deployment across diverse terrain throughout China.
Dimensions
Length INA
Height INA
Wingspan INA
Weight, Maximum 1,300 kg
Automotive
Engine Name DB416
Engine Type heavy oil piston engine
Engine Power INA
Maximum Speed 230 km/h
Cruise Speed 150-180 km/h
Maximum Range 4,000 km
Service Ceiling 9,000 m
Endurance 30 hours
Armament
Note Equipped to carry the AR-1 air-to-surface missiles, which are air-to-ground guided weapons comparable to the AGM-114 Hellfire.
Details
Country of Origin China
Category UAVs
Air > UAVs
Filter Label
K
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
1300 kg
Operators (1)
China
