Rodman 78 Class Indian Immediate Support Vessel
Rodman 78 Class
Immediate Support Vessel
Other
Basic Information
Name
Rodman 78 Class Indian Immediate Support Vessel
Designation
Rodman 78 Class
Alternate Designation
Rodman 78 Class
Equipment Type
Immediate Support Vessel
Manufacturer
Rodman Polyships
Date of Introduction
2014
Description
The Rodman 78 Class Indian Immediate Support Vessel. An order for 23 Immediate Support Vessels (ISV) was made in 2013 of which nine Rodman 78 craft were built by Abu Dhabi Ship Building (four) and Rodman Polyships, Vigo (five). The craft are of GRP construction. While the vessels are to be operated by the Marine Commando Force, they were funded by the Oil and Natural Gas Corporation. The role of the vessels is to carry out day and night surveillance of offshore installations and general security operations.
Naval & Littoral Specifications
Crew
5
Beam
5.10 m
Draft
0.93 m
Variants
T-11, T-12, T-13, T-14, T-15, T-16, T-17
Commissioned: 2014
Status: Active
T-35, T-36, T-37
Commissioned: 2014
Status: Active
T-26, T-27, T-28
Commissioned: 2015
Status: Active
T-44, T-45, T-46, T-47
Commissioned: 2015
Status: Active
T-48, T-49, T-50
Commissioned: 2015
Status: Active
T-38, T-39, T-40
Commissioned: 2015
Status: Active
System
Alternative Designation
Rodman 78 Class
Type
Immediate Support Vessel
Builder
SHM Shipcare;
Abu Dhabi Ship Builders (ADSB);
Rodman 78
Crew
5 ea
Dimensions
Length
23.5 m
Height
INA
Beam
5.1 m
Draft
0.93 m
Displacement, Full Load
59 tons
Propulsion System
Engine Name
2 x Caterpillar C32
Engine Type
Diesel
Engine Power
2 × 1,600 hp
Propulsion
Waterjets
Maximum Range
200 n miles (370.4 km) (230.2 miles) at 20 kt (37.0 km/h) (23.0 mph)
Maximum Speed
40 kt (74.1 km/h) (46.0 mph)
Main Weapon System
Note
1 x 12.7 mm MG; 1 x 7.62 mm MG.
Radar Systems
Ssurface Search/Navigation Radar
1 x I-Band Radar
Protection
Hull
INA
Countermeasures
INA
NBC Water Washdown System
INA
EW Intercept
INA
Details
Country of Origin
India
Category
Support Ships
Naval > Support Ships
Filter Label
R
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
23.5 m
Width
5.1 m
Height
—
Weight
59000 kg
Operators (1)
India
