BTR-4MV1 Ukrainian 8x8 Amphibious Armored Personnel Carrier (APC)
BTR-4MV1
Amphibious Armored Personnel Carrier (APC)
Other
Basic Information
Name
BTR-4MV1 Ukrainian 8x8 Amphibious Armored Personnel Carrier (APC)
Designation
BTR-4MV1
Alternate Designation
BTR-4MV1
Equipment Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Ukraine Defense Industry
Date of Introduction
2017
Description
The BTR-4MV1 Ukrainian 8x8 Amphibious Armored Personnel Carrier (APC) is a further development of the previous BTR-4MV.
Ground Specifications
Crew
3
Mobility Type
Wheeled (8x8)
Main Weapon
30 mm Automatic Cannon
Engine
Diesel (450 hp)
NBC Protection
Yes
Max Speed
110.0 km/h
Range
700.0 km
Variants
BTR-4MV
The BTR-4MV Ukrainian 8x8 Amphibious Armored Personnel Carrier (APC) is an improved and up-armored version of the BTR-4.
System
Alternative Designation
BTR-4MV1
Type
Amphibious Armored Personnel Carrier (APC)
Manufacturer
Ukraine Defense Industry
Configuration
8x8
Crew
3 ea
Passengers
7 ea
Dimensions
Length
7.65 m
Width
2.9 m
Height
2.86 m
Weight, Combat
21.9 tons tons
Weight, with Add-on Armor Kit
23.6 tons
Automotive
Engine Name
Deutz BF6M 1015 CP
Engine Type
Diesel
Engine Power
450 hp
Maximum Range
700 km
Maximum Land Speed
110 km/h
Amphibious Speed
10 km/h
Gradient
60%
Side Slope
40%
Vertical Step
0.6 m
Trench
2.0 m
Fording
Amphibious
Main Weapons System
Turret
BM-7 Parus unmanned turret
Note
1 x 30 mm Automatic Cannon
Basic Load
408 rounds
Coaxial Weapon System
Note
1 x 7.62mm General-Purpose Machine Gun
Basic Load
1,500 rounds
Grenade Launcher
Note
1 x 30 mm Automatic Grenade Launcher
Basic Load
87 grenades
Anti-Tank Guided Missile (ATGM) System
Note
2 x Launchers for the Baryer Anti-Tank Guided Missiles.
Basic Load
4 x Baryer Anti-Tank Guided Missiles.
Protection
Armor
All-round protection of the base armor is against NATO 7.62x51 mm armor-piercing rounds. Ballistic protection corresponds with STANAG 4569 Level 3. Front arc withstands hits from at least 12.7 mm rounds. Vehicle withstands mine blasts equivalent to 8 kg of TNT.
Turret Armor
The turret is fitted with a cage armor, which provides protection against anti-tank rockets and missiles.
Applique Armor
Available, Add-on spaced armor plates are bolted all around the hull over the base armor.
NBC Protection
Yes
Smoke Equipment
INA
Image Sources
Notes
https://twitter.com/Defence_blog/status/1097042037516443648; https://www.armyrecognition.com/arms_and_security_2017_online_show_daily_news/the_btr-4mv1_is_presented_for_the_first_time_in_ukraine_at_arms_security_2017.html; https://www.dreamstime.com/kiev-ukraine-october-new-ukrainian-armored-vehicle-btr-mv-exhibition-arms-security-new-ukrainian-armored-vehicle-btr-mv-image101734219;
Details
Country of Origin
Ukraine
Category
Land
Land
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
7.65 m
Width
2.9 m
Height
2.86 m
Weight
21900 kg
Operators (1)
Ukraine
