Ural-63708 Russian 8x8 Heavy Equipment Transport Truck
Ural-63708
Heavy Armored Personnel Carrier (APC)
Other
Basic Information
Name
Ural-63708 Russian 8x8 Heavy Equipment Transport Truck
Designation
Ural-63708
Alternate Designation
Ural-63708
Equipment Type
Heavy Armored Personnel Carrier (APC)
Manufacturer
Ural Automobile Plant
Date of Introduction
2016
Description
The Ural-63708 is a new Russian tractor truck with an 8x8 configuration. It is a version of the Ural-63704-0010 military truck with an added axle at the rear and fitted with a more powerful engine. It was first publicly revealed in 2016. This tractor truck is a member of the Tornado-U family of military vehicles. In this case letter "U" in the designation stands for "Ural", as there is also a similar KamAZ-U family, developed by another Russian truck manufacturer KamAZ.
Ground Specifications
Crew
1
Engine
Diesel (600 hp)
System
Alternative Designation
Ural-63708
Type
Heavy Equipment Transport Truck
Configuration
8x8
Manufacturer
Ural
Crew
1 ea
Passenger Capacity
5 ea
Payload Capacity
up to 70 tons
Dimensions
Length
10.37 m
Width
2.55 m
Height
3.15 m
Weight, Tractor
15 tons
Weight, Tractor and Trailer
30 tons
Gross Combination Weight
Up to 100 tons
Automotive
Engine Name
YaMZ
Engine Type
Diesel
Engine Power
600 hp
Cruising Range
800 km
Speed, Maximum Road
90 km/h
Speed, Average Cross
INA
Gradient, Unloaded
25 %
Gradient, Loaded
10-15 %
Side Slope, Tractor
30 %
Vertical Step
0.6 m
Trench
INA
Fording Depth, Loaded
0.7 m
Fording Depth, Tractor
Up to 1.8 m
Main Weapon System
Note
There are no crew-served weapons mounted on the Ural-63708 Russian 8x8 Heavy Equipment Transport Truck
Protection
Hull Armor
INA
Applique Armor
INA
NBC Equipment
INA
Smoke Equipment
INA
Image Sources
Notes
INA;
Details
Country of Origin
Russia
Category
Transportation
Land > Combat Support Vehicles > Transportation
Filter Label
U
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
10.37 m
Width
2.55 m
Height
3.15 m
Weight
100000 kg
Operators (1)
Russia
