Taian TA4360 (TAS4360) Chinese 6x6 Tank Transporter
Taian TA4360
Tank Transporter
Other
Basic Information
Name
Taian TA4360 (TAS4360) Chinese 6x6 Tank Transporter
Designation
Taian TA4360
Alternate Designation
Taian TA4360; TAS4360
Equipment Type
Tank Transporter
Manufacturer
Taian Special Vehicle Company
Date of Introduction
1998
Description
The Taian TA4360 (TAS4360) Chinese 6x6 Tank Transporter is used to transport tanks, tracked self-propelled artillery systems, various armored vehicles and construction material over long distances.
Ground Specifications
Crew
6
Mobility Type
Wheeled (6x6)
Engine
Diesel (517 hp)
Max Speed
73.0 km/h
Range
1000.0 km
System
Alternative Designation
Taian TA4360; TAS4360
Type
Tank Transporter
Manufacturer
Taian Special Vehicle Company
Configuration
6x6
Cab Seating
1 + 5
Payload Capacity
50 tons
Winch
There are winches at the back of the cab for loading operations. These are used to load disabled or immobile vehicles.
Dimensions
Length
8.0 m
Width
3.3 m
Height
3.2 m
Weight, Empty
15 tons
Automotive
Engine Name
Deutz
Engine Type
Diesel
Engine Power
517 hp
Range
1,000 km
Speed, Maximum Road
73 km/h
Speed Maximum Swim
Not Amphibious
Gradient, Empty
60%
Gradient, Loaded
28%
Side Slope
28%
Vertical Step
INA
Trench
INA
Fording
1.2 m
Main Weapon System
Note
There are no crew-served weapons mounted on the Taian TA4360 (TAS4360) Chinese 6x6 Tank Transporter.
Protection
Armor
INA
Applique Armor
INA
NBC Protection
INA
Smoke Equipment
No
Details
Country of Origin
China
Category
Transportation
Land > Combat Support Vehicles > Transportation
Filter Label
T
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8 m
Width
3.3 m
Height
3.2 m
Weight
15000 kg
Operators (2)
China
Venezuela
