2S25 Sprut-SD Russian Light Amphibious Tank
2S25 Sprut-SD
Amphibious Light Tank
Other
Basic Information
Name
2S25 Sprut-SD Russian Light Amphibious Tank
Designation
2S25 Sprut-SD
Alternate Designation
2S25 Sprut-SD
Equipment Type
Amphibious Light Tank
Manufacturer
Volgograd Tractor Plant
Date of Introduction
2005
Description
The 2S25 Sprut-SD Russian Light Amphibious Tank is a self-propelled tank destroyer or light tank developed and manufactured by the Volgograd Tractor Plant to meet the requirements of the VDV. In mid-2001, the Volgograd tractor plant revealed that the development of the 2S25 had lasted several years. The Sprut-SD is designed to defeat tanks, hard-skinned material, and enemy manpower by airborne and amphibious landing forces, as well as by specially designated units of ground forces. Its main armament, the 2A75, is capable of firing APFSDS, HE-Frag, HEAT, and ATGM ammunition. This allows the 2S25 firepower to be as powerful as the main battle tank and as maneuverable and amphibious as airborne infantry combat vehicles. The 2S25 can be used by units of ground forces and naval infantry as a light amphibious tank.
Ground Specifications
Crew
3
Mobility Type
Tracked
Main Weapon
125 mm 2A75 smoothbore gun
Engine
Diesel (510 hp)
NBC Protection
Yes
Max Speed
70.0 km/h
Range
500.0 km
Variants
Sprut-SDM1
New version with fire-control system and remote weapon station.
System
Alternative Designation
2S25 Sprut-SD
Type
Russian Light Amphibious Tank
Manufacturer
Volgograd Tractor Plant
Crew
3 ea
Dimensions
Length, Gun Forward
9.77 m
Length, Chassis
7.08 m
Width
3.15 m
Height
2.72 m
Weight, Combat
18 Tons
Ground Pressure
INA
Automotive
Engine Name
2V-06-2S
Engine Type
water cooled diesel engine
Engine Power
510 hp
Range
500 km
Speed, Maximum Road
70 km/h
Speed, Maximum Off-Road
45 km/h
Speed Maximum Swim
10 km/h
Gradient
60 %
Side Slope
30 %
Vertical Step
0.9 m
Trench
1.8 m
Fording
Amphibious
Main Gun
System
Name
1 x 2A75 smoothbore gun
Type
Smoothbore Gun
Caliber
125 mm
Length
INA
Barrel Length
0.925 m
Width
INA
Elevation
- 5 to + 15 degrees
Traverse
360 degrees
Autoloader
Yes
Rate of Fire
The 2s25 Sprut SD has a rate of fire of 7 rounds per minute.
Maximum Effective Fire
5 km
Note
This gun is also used to launch anti-tank guided missies in the same manner as ordinary projectiles. This feature is common to all modern Russian MBTs. Laser-guided anti-tank missiles has a range of effective fire of up to 5 km.
Ammunition
Type
Projectile
Caliber
125 mm
Basic Load
40 Rounds
Note
The gun uses the same ammunition as the D-81 series of guns used on the T-64, T-72, T-80 and T-90 tanks.
Coaxial Weapon System
System
Name
1 x PKT
Type
General-Purpose Machine Gun
Caliber
7.62 mm
Length
1,203 mm
Barrel Length
605 mm
Weight
9 kg
Maximum Rate of Fire
650 rds/min
Effective Rate of Fire
250-300 rds/min
Action
Gas-operated, open bolt
Maximum Firing Range
4,000 m
Effective Firing Range (with Sight Adjustments)
100-1,500 m
Feed System
Non-disintegrating metal 50 round belts in 100 and 200/250 round ammunition boxes
Sights
Iron Sights/ Optics (optional)
Ammunition
Type
Rifle
Caliber
7.62 mm
Cartridge
7.62×54mmR
Basic Load
INA
Fire Control
Name
INA
Computerized FCS
Yes, a modernized FCS
Thermal Sight Tank Commander
INA
Thermal Sight Gunner
INA
Main Gun Stabilization
Yes
Protection
Hull Armor
The hull of the 2S25 self-propelled anti-tank gun is composed of welded aluminum armor with a composite skin to maintain a light weight. Through the frontal arc, 40° left and right of the frontal armor provides protection against attack from 23 mm weapons at 500 m (550 yd) and against small arms fire and shell splinters through the remainder of the vehicle.
Turret Armor
Turret – Welded steel
Applique Armor
Available
Explosive Reactive Armor
INA
Active Protection System
INA
Mine Clearing
INA
Self-Entrenching Blade
INA
NBC Protection
Yes
Smoke Equipment
Two banks of three smoke-grenade dischargers are mounted towards the rear on each side of the turret as countermeasures to infrared weapons.
Automatic Fire Suppression System
Yes
Details
Country of Origin
Russia
Category
Tanks
Land > Tanks
Filter Label
2
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
9.77 m
Width
3.15 m
Height
2.72 m
Weight
18000 kg
Operators (1)
Russia
