EVO Lite Chinese Unmanned Aerial Vehicle (UAV)
EVO Nano
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
EVO Lite Chinese Unmanned Aerial Vehicle (UAV)
Designation
EVO Nano
Alternate Designation
EVO Nano
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Autel Robotics
Date of Introduction
2020
Description
The EVO Lite Chinese Unmanned Aerial Vehicle (UAV) is the only drone of its size to offer an endurance of 40 minutes, giving you 30 percent more flight time than the competition.
Air & Air Defense Specifications
Engine
Battery
System
Alternate Designation
EVO Nano
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
Autel Robotics
Autonomy
Semi-Autonomous
Crew
Unmanned
Operating Frequency
2.400-2.4835GHz，5.725-5.850GHz,5.150-5.250GHz
Transmission Power (EIRP)
FCC: ≤30dBm；CE: ≤20dBm
GNSS
GPS, GLONASS, Galileo
Operating Temperature
0°C ~ 40°C
Launching System
Vertical Take-Off and Landing (VTOL)
Recovery System
Vertical Take-Off and Landing (VTOL)
Dimensions
Length, Folded
210 mm
Width, Folded
123 mm
Height, Folded
95 mm
Length, Unfolded
427 mm
Width, Unfolded
384 mm
Height, Unfolded
95 mm
Wheelbase
368 mm
Maximum Takeoff Weight
835 grams
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Max Ascent Speed
5m/s (ludicrous), 4m/s (standard), 3m/s (smooth)
Max Descent Speed
4m/s (ludicrous), 3m/s (standard), 2m/s (smooth)
Max Level Flight Speed(no wind, near sea level)
18m/s (ludicrous), 10m/s (standard), 5m/s (smooth)
Max Takeoff Altitude
4,000 m
Max Flight Time (no wind)
40 min
Max Hovering Time (no wind)
38 min
Max Flight Distance (no wind)
24 km
Max Wind Resistance
15 m/s (In flight)12 m/s (Take-off and landing)
Max Tilt Angle
33°(ludicrous), 25°(standard), 25°(smooth)
Max Angular Velocity
200°(ludicrous), 120°(standard), 60°(smooth)
Hovering Accuracy
Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning).
Image Sources
Notes
https://www.rcgoing.com/autel-robotics-evo-lite-lite-series-12km-fpv-with-6k-30fps-video-4-axis-gimbal-40mins-flight-time-obstacle-avoidance-rc-drone-quadcopter/; https://www.walmart.com/ip/EVO-Lite-Premium-Bundle-with-128GB-microSD-Card-Anti-Collision-Light-Landing-Pad/1037884724; https://www.ebay.com/p/6053102109;
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
E
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
0.84 kg
Operators (1)
China
