VSR700 French Unmanned Aerial Vehicle (UAV)

VSR700

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
VSR700 French Unmanned Aerial Vehicle (UAV)
Designation
VSR700
Alternate Designation
VSR700
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Airbus
Date of Introduction
2025
Description

The VSR700 French Unmanned Aerial Vehicle (UAV) is a vertical take-off and landing (VTOL) unmanned aerial vehicle designed to operate from naval surface combatants (frigates, destroyers) alongside manned helicopters. Developed under the French Navy's SDAM program, it bridges the gap between smaller tactical drones (like the Skeldar V-200) and large rotary-wing UAVs (like the MQ-8C Fire Scout). The platform is derived from the Guimbal Cabri G2 light manned helicopter, converted into an optionally piloted vehicle (OPV) and eventually a fully unmanned system. Its primary role is Intelligence, Surveillance, Target Acquisition, and Reconnaissance (ISTAR), with secondary capabilities in Anti-Submarine Warfare (ASW) and limited strike operations. The VSR700 occupies a distinct "middle weight" tier. It offers significantly more payload and stability than the smaller Skeldar V-200 but is more logistically deployable than the heavy MQ-8C Fire Scout, which requires a larger hangar footprint comparable to a manned helicopter.

Air & Air Defense Specifications
Engine Heavy-Fuel Engine (155 hp)
Max Speed 185.0 km/h
Range 150.0 km
Endurance 8.00 hrs
Service Ceiling 6000 m
Rotor Diameter 7.20 m
Payload Capacity 0 kg
System
Alternate Designation VSR700
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Airbus
Payload Capacity 00 kg (Tactical); Up to 250 kg for short-range logistics
Sensors (ISTAR & ASW) Maritime Radar: Typically equipped with the Thales AirMaster C, an ultra-compact AESA radar utilizing SiGe (Silicon Germanium) technology. It weighs ~20 kg and provides 2D surveillance capabilities for surface search and target tracking. EO/IR Optronics: Safran Euroflir 410 turret. High-definition electro-optical and infrared sensors with laser designation and range-finding capabilities. ASW Suite: Capable of carrying and deploying Thales Sonoflash active/passive sonobuoys. It can relay acoustic data back to the mothership, acting as a remote sensor extension for the ship's ASW screen. AIS: Automatic Identification System receiver for correlating surface tracks.
DeckFinder An Airbus-proprietary local positioning system that enables ATOL operations without GPS reliance (GNSS-denied environments).
Sea State Capability Certified for launch and recovery in Sea State 5 (waves up to 4m) on a moving frigate deck.
Dimensions
Length 6.25 m
Height 2.28 m
Rotor Diameter 7.20 m
Maximum Takeoff Weight 700–760 kg
Automotive
Engine Name Continental CD-155 (Thielert Centurion 2.0)
Engine Type Heavy-fuel (Jet A-1/Diesel) piston engine
Engine Power 155 hp (114 kW)
Maximum Speed 185 km/h
Cruise Speed INA
Maximum Range 150 km
Service Ceiling 6,000 m
Endurance 8 hours with full tactical sensor load
Main Weapon System
Note As of mid-2025, Airbus has validated a strike configuration to counter asymmetric threats (fast attack craft). Hardpoints: Two side-mounted pylons. Weapons: Thales FZ602: 2-tube launcher for 70mm laser-guided rockets (FZ275 LGR). Akeron MP: Potential integration path for anti-surface missiles (MBDA), though primary armed configuration display focused on guided rockets.
Details
Country of Origin France
Category UAVs
Air > UAVs
Filter Label
V
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
6.25 m
Width
Height
2.28 m
Weight
700 kg
Operators (1)
France
