FLIR Recon V American Multi-Sensor Thermal Binoculars

FLIR Recon V

Multi-Sensor Thermal Binoculars
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
FLIR Recon V American Multi-Sensor Thermal Binoculars
Designation
FLIR Recon V
Alternate Designation
FLIR Recon V
Equipment Type
Multi-Sensor Thermal Binoculars
Manufacturer
Date of Introduction
2018
Description

The Recon V is a compact and light yet rugged multi-sensor thermal binocular designed for 24/7 day and night field operations that require enhanced imagery and long standoff range. Its internal GPS, DMC, and long-range laser pointer provide accurate range to target as well as precise location. The 10x continuous zoom optics, MEMS based electronic stabilization, and high-definition color video display combine to provide unmatched image quality and flexibility. Powered by AA Li batteries, the unit has a run time of up to six hours. It’s SWaP-optimized and qualified to MIL-STD 810G for easy portability under rigorous mission demands. An intuitive interface reduces training time and simplifies usability in high-stress field operations. While operators provide mission-critical situational awareness data they remain safe by always being connected to their extended team. Features: *BEST-IN-CLASS THERMAL IMAGING Combining 640x480 MWIR image quality with industry-leading processing and a high-definition display, Recon V provides the clarity your mission demands. *POWERFUL TACTICAL CAPABILITIES Built-in stabilization, digital magnetic compass, GPS, and laser pointer provide accurate range-to-target, precise geo-location, and rock-solid imagery. *FLEXIBLE, TOUGH, AND POWERFUL SWaP-optimized and easy to use, Recon V minimizes operator fatigue and is rugged enough to survive everything your mission may throw at it. *INCREASED SITUATIONAL AWARENESS 10x continuous zoom provides long-range narrow FOV as well as wide-angle FOV for battlefield flexibility. *EASY, INTUITIVE OPERATION An intuitive interface includes electronic stabilization (E-Stab), one shot image save, auto fall-of-shot, auto image optimization, auto focus and BIT,

Ground Specifications
Crew 1
Variants
Recon V Ultra Lite Fully operational at less than three pounds, the breakthrough Recon V Ultra Lite provides long-range target detection, recognition, recording and geo-location with an HD color camera and dual FOV thermal channels. Powered by commercially available AA batteries, the unit has a run time greater than four hours with smart power management. Combined with a highly accurate laser range finder, GPS, digital magnetic compass and intuitive user interface, targets can be quickly located 24/7.
System
Alternative Designation FLIR Recon V
Type Multi-Sensor Thermal Binoculars
Crew 1 ea
Sensor Type 640 x 480 InSb
Telescope 10X Zoom 27-275mm
WFOV 20° x 15°
NFOV 2° x 1.5°
Display Type OLED, Full Color
Display Resolution 1280x720, (720p) 16:9
Frame Rate 60Hz
Image Controls Cal, Pol, Auto/ Man Gain, Display, Auto Focus, Palettes
Global Positioning System (GPS) C/A code
SAASM GPS supports military GPS plug-in (optional)
Digital Magnetic Compass 360° Az, +/- 90° El, 0.2° resolution
Laser Rangefinder (LRF) 1.54 μm, Eyesafe, class 1, 10km
Laser Pointer (LP) 852 nm, Class 3B, .5/30mW (optional)
Image Storage Yes, 1000 png
E-Stabilization MEMS Gyro, No image latency
Battey Type AA Lithium
Run Type 6 hours (Hot Swap)
External Power 9-32VDC
Video NTSC/ PAL & HD-SDI
Optional Accessories Remote LRF Cable; Communications Cable; DAGR Cable
Dimensions
Length 8.7 in
Width 7.4 in
Height 3.5 in
Weight, Combat 4.25 lbs
Details
Country of Origin United States
Category Land Based Sensors
Land > Land Based Sensors
Filter Label
F
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
0.22 m
Width
0.19 m
Height
0.09 m
Weight
1.93 kg
Operators (1)
United States
