CS/VP4 Chinese 6x6 All-Terrain Vehicle (ATV)
CS/VP4
All-Terrain Vehicle (ATV)
Other




Basic Information
Name
CS/VP4 Chinese 6x6 All-Terrain Vehicle (ATV)
Designation
CS/VP4
Alternate Designation
CS/VP4
Equipment Type
All-Terrain Vehicle (ATV)
Manufacturer
The Lynx is believed to have been developed by the state-owned Chongqing-based China Jialing Industrial Co Ltd (Group), a subsidiary of NORINCO.
Date of Introduction
2012
Description
The CS/VP4 Chinese 6x6 All-Terrain Vehicle (ATV) is believed to have been developed and manufactured by the Chongqing-based China Jialing Industrial Co Ltd (Group), a subsidiary of NORINCO. In addition to the 8×8 configuration covered in this entry, other configurations of the same/similar platform have been shown, including the 6×6 CS/VP16.
Ground Specifications
Crew
1
Mobility Type
Wheeled (6x6)
Engine
1.4-liter, 4-cylinder, water-cooled diesel (30 hp)
Amphibious
Yes
Max Speed
60.0 km/h
Range
400.0 km
Variants
CS/VP16
INA
System
Alternative Designation
CS/VP4
Type
All-Terrain Vehicle (ATV)
Manufacturer
The Lynx is believed to have been developed by the state-owned Chongqing-based China Jialing Industrial Co Ltd (Group), a subsidiary of NORINCO.
Configuration
6x6
Crew
1 ea
Passengers
5 ea
Payload Capacity
650 kg (amphibious with around 300 kg payload (est.))
Towing Capacity
1,500 kg
Dimensions
Length
3.84 m
Width
1.792 m
Height
1.8 m
Weight, Empty
1,100 kg
Weight, Combat
1,750 kg
Automotive
Engine Name
Yuchai YC4W85-30
Engine Type
1.4-litre, 4-cylinder, water-cooled diesel
Engine Power
30 hp
Maximum Range
400 km
Maximum Speed
60 km/h
Amphibious
Yes
Amphibious Speed
4 km/h
Gradient
>60%
Side Slope
>40%
Vertical Step
300 mm
Trench
INA
Protection
Armor
INA
Applique Armor
No
NBC Protection
No
Smoke Equipment
No
Image Sources
Notes
https://twitter.com/Nickatgreat1220/status/1576103867292360704; https://en.topwar.ru/135136-mnogocelevoy-vezdehod-norinco-cs-vp4-kitay.html; https://forum.warthunder.com/t/norinco-8x8-cs-vp4-multi-purpose-all-terrain-vehicles/15881; https://china-defense.blogspot.com/2015/02/photos-of-day-airborne-infantry.html;
Details
Country of Origin
China
Category
Wheeled All-Terrain Vehicles
Land > All-Terrain Vehicles > Wheeled All-Terrain Vehicles
Filter Label
C
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
3.84 m
Width
1.79 m
Height
1.8 m
Weight
1750 kg
Operators (1)
China
