IRIS American 4x4 Unmanned Ground Vehicle (UGV)
IRIS American 4x4 Unmanned Ground Vehicle (UGV)
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
IRIS American 4x4 Unmanned Ground Vehicle (UGV)
Designation
IRIS American 4x4 Unmanned Ground Vehicle (UGV)
Alternate Designation
IRIS American 4x4 Unmanned Ground Vehicle (UGV)
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Roboteam
Date of Introduction
2021
Description
The IRIS American 4x4 Unmanned Ground Vehicle (UGV) is a miniature, fast deployable, ruggedized, hand-carried, unmanned systems. It is designed to support several units such as SWAT, Public Safety, Military, and Law Enforcement. The IRIS® can enter small and confined spaces, above or underground, to explore hazardous areas while relaying intelligence and reconnaissance information in real time. IRIS (Individual Robotic Intelligence System).
Air & Air Defense Specifications
Max Speed
4.0 km/h
Payload Capacity
1 kg
System
Alternate Designation
IRIS American 4x4 Unmanned Ground Vehicle (UGV)
Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Roboteam
Configuration
4x4
Communication
Secure digital encrypted
Payload Capacity
1 kg
Payload Ports
CAN bus, 5V, 12V, RS232*
Video & Cameras
2 integrated cameras for real time day & night video + zoom,
laser & audio
Sensor Tilt Module
-60° / +70°
Illumination Module
NIR LED, adjustable brightness
Operational Temperature (MIL STD.)
-4° to 140°F / -20° to 60°C
Environmental
IP65
Dimensions
Length
24 cm
Width
20.5 cm
Height
11 cm
Weight
1.85 kg
Automotive
Power Supply
12V Replaceable battery
Maximum Speed
4 km/h
OperatingRange
200 m LOS
Details
Country of Origin
United States
Category
UAVs
Air > UAVs
Filter Label
I
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
0.24 m
Width
0.21 m
Height
0.11 m
Weight
1.85 kg
Operators (1)
United States
