Dyugon Class (Project 21820 Class) Russian Landing Craft
Dyugon Class
Landing Craft
Other
Basic Information
Name
Dyugon Class (Project 21820 Class) Russian Landing Craft
Designation
Dyugon Class
Alternate Designation
Dyugon Class; Project 21820 Class
Equipment Type
Landing Craft
Manufacturer
Yaroslavl Shipyard
Date of Introduction
2010
Description
The Dyugon Class landing craft, or Project 21820, is a class of landing craft being constructed for the Russian Navy. A total of five Project 21820 class landing craft are in service with the Russian Navy. The ships are intended to deliver troops and wheeled and tracked vehicles from the sea to the unequipped coasts during an amphibious assault.
Ground Specifications
Crew
7
Main Weapon
2 x KPVT 14.5mm Heavy Machine Gun
Max Speed
65.0 km/h
Range
926.0 km
Variants
D-105
Commissioned: 2010
Status: Active
Fleet: INA
Ataman Platov
Commissioned: 2010
Status: Active
Fleet: Caspian Fleet
Denis Davydov
Commissioned: 2014
Status: Active
Fleet: Baltic Fleet
Ivan Kartsov
Commissioned: 2015
Status: Active
Fleet: Pacific Fleet
Lieutenant Rimskij-Korsakov
Commissioned: 2015
Status: Active
Fleet: Baltic Fleet
Midshipman Lermontov
Commissioned: 2015
Status: Active
Fleet: Baltic Fleet
System
Alternative Designation
Dyugon Class; Project 21820 Class
Type
Landing Craft
Builder
Yaroslavl Shipyard
Crew
7 ea
Cargo Capacity
3 x T-72 main battle tanks or 5 x BTR-80 and 50 x troops or 1 x T-72 main battle tank (or BTR-80) and 90 x troops or 140 tons of cargo.
Note
A distinctive feature of the ship is an artificial air cavity on the bottom to achieve high speed and efficiency in the movement. The first ships dynamically supported were based on static air cushions with powerful fans and a huge fuel consumption. The air cavity vessels are more economical than the hovercraft. In both types of the special contours of the bottom is a layer for holding compressed air.
Dimensions
Length
45 m
Beam
8.6 m
Draft
2.2 m
Cargo Deck, Length
27 m
Cargo Deck, Width
6.8 m
Cargo Deck, Height
2.34 m
Displacement, Standard
INA
Displacement, Full Load
280 tons
Propulsion System
Engine Name
2 x М507А-2-010М3
Engine Type
Diesel
Engine Power
9,000 hp
Maximum Range
500 nm
Maximum Speed
35 knots (65 km/h)
Endurance
INA
Gun Weapon System
System
Name
2 x KPVT 14.5mm Heavy Machine Gun
Type
Heavy Machine Gun
Caliber
14.5 mm
Length
1,980 mm
Barrel Length
1,346 mm
Width
162 mm
Height
225 mm
Weight
49 kg
Action
Short recoil operation
Rate of Fire
600 rpm
Muzzle Velocity
1,005 m/s
Maximum Firing Range
4,000 m
Effective Firing Range
3,000 m
Feed System
40-round belt
Sights
iron or optical
Ammunition
Type
Rifle
Caliber
14.5 mm
Cartridge
14.5×114 mm
Basic Load
INA
Radar
Navigation Radar
INA
Protection
Hull
INA
Countermeasures
INA
NBC Water Washdown System
Yes
Image Sources
Note
https://navyrecognition.com/index.php/naval-news/naval-news-archive/2017/february-2017-navy-naval-forces-defense-industry-technology-maritime-security-global-news/4881-russian-baltic-fleet-hovercraft-land-marines-onto-rough-terrain-in-amphibious-drills.html; https://www.reddit.com/r/WarshipPorn/comments/3gvnu0/russian_dyugon_class_landing_craft_1000x666/;
Details
Country of Origin
Russia
Category
Naval
Naval
Filter Label
D
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
45 m
Width
8.6 m
Height
—
Weight
280000 kg
Operators (1)
Russia
