Spector M1 (Meridian) Ukrainian Unmanned Aerial Vehicle (UAV)
Spector M1
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Spector M1 (Meridian) Ukrainian Unmanned Aerial Vehicle (UAV)
Designation
Spector M1
Alternate Designation
Spector M1; Meridian
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
OJSC 'Meridian' n. S. P. Korolyov
Date of Introduction
2018
Description
The Spector M1 (Meridian) Ukrainian Unmanned Aerial Vehicle (UAV) is a mini-UAV designed for surveillance and reconnaissance missions. It is also designed to have a low visual signature and high aerodynamic properties.
Air & Air Defense Specifications
Engine
1 × Electric motor that driving a tractor propeller.
Max Speed
120.0 km/h
Range
50.0 km
Endurance
180.00 hrs
Service Ceiling
2000 m
Wingspan
3.02 m
Payload Capacity
1 kg
System
Alternate Designation
Spector M1; Meridian
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
OJSC ‘Meridian' n. S. P. Korolyov
Autonomy
Automatic, semi-automatic and manual control modes.
Crew
Unmanned
Composition
A complete system is comprised of; one to three AVs, a ground station, a radio control panel, a plug-in battery kit, and an antenna array.
Guidance System
Automatic, semi-automatic, and manual control modes. Advanced ground control station.
Payload Capacity
1.5 kg
Mission Payloads
Day/night camera, IR camera, multispectral camera, high resolution photo camera, and radiation sensors.
Launching System
Hand-launched.
Recovery System
Parachute landing or belly landing.
Note
Spectator-M1 reported to be in service with the Ukrainian State Border Guard Service
Dimensions
Length
1.345 m
Wingspan
3.02 m
Height
INA
Maximum Takeoff Weight
7 kg
Backpack Dimensions
1,300 × 400 × 200 mm
Automotive
Engine Name
INA
Engine Type
1 × Electric motor that driving a tractor propeller.
Engine Power
INA
Maximum Speed
120 km/h
Cruising Speed
40 km/h
Service Ceiling
2,000 m
Radius of Operation
20 km
Endurance
180 min
Maximum range
50 km
Details
Country of Origin
Ukraine
Category
UAVs
Air > UAVs
Filter Label
S
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.35 m
Width
—
Height
—
Weight
7 kg
Operators (1)
Ukraine
