Bayonet 150 American Amphibious Unmanned Ground Vehicle (UGV)

Bayonet 150

Unmanned Ground Vehicle (UGV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Bayonet 150 American Amphibious Unmanned Ground Vehicle (UGV)
Designation
Bayonet 150
Alternate Designation
Bayonet 150
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Greensea
Date of Introduction
2022
Description

The Bayonet 150 American Amphibious Unmanned Ground Vehicle (UGV) is the most compact in the Bayonet series, offering exceptional portability and ease of deployment. Operating from the sea floor to the beachhead, Bayonet AUGVs travel through the harshest conditions where other systems cannot. Designed to be carried by two persons, this AUGV is ideal for smaller payloads and lighter weather and surf conditions. Its reduced size and weight make it perfect for space-constrained applications, offering more effortless mobility and lower logistics. Despite its more diminutive stature, the Bayonet 150 does not compromise on capability, providing reliable performance in various scenarios.

Ground Specifications
Mobility Type Track
Engine Battery
Amphibious Yes
Range 14.8 km
System
Alternative Designation Bayonet 150
Type Amphibious Unmanned Ground Vehicle (UGV)
Manufacturer Greensea
Configuration Track
Crew Unmanned
Deck Capacity 22.7 kg continuous; 124.7 kg peak
Sensor Packages Standard: Depth Sensor - Keller Scientific; Camera - Sidus SS400IP; Forward Looking Sonar - Oculus 750, 1200; GPS - Ublox / Advanced Navigation; IP Radio - 70Mbs (approximate), LOS 100 meters. Optional: ACOMMS - Benthos, Oceancomm; RTK GPS - Trimble R12.
Dimensions
Length 111.76 cm
Width 91.44 cm
Height 25.4 cm
Open Deck Space 66 cm x 30.5 cm
Weight, with Batteries 131.54 kg
Automotive
Engine Name INA
Engine Type Battery
Engine Capacity 2 kWh
Maximum Range 14.8 km
Maximum Speed INA
Amphibious Yes
Maximum Depth 100 m
Endurance 6 hours
Protection
Armor INA
Details
Country of Origin United States
Category Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
1.12 m
Width
0.91 m
Height
0.25 m
Weight
131.54 kg
Operators (1)
United States
