Wei Lai Class Chinese Deep-Sea Research Vessel

Wei Lai Class

Deep-Sea Research Vessel
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Wei Lai Class Chinese Deep-Sea Research Vessel
Designation
Wei Lai Class
Alternate Designation
Wei Lai Class
Equipment Type
Deep-Sea Research Vessel
Manufacturer
Shanghai Ship Research and Design Institute
Date of Introduction
2025
Description

The Wei Lai Class Chinese Deep-Sea Research Vessel is China’s latest advanced research ship, designed as a multifunctional platform for deep-sea exploration, oceanographic surveys, and testing of advanced marine technologies. This vessel signifies a major step forward in China’s commitment to technological innovation and environmental protection in the maritime sector. One of the most distinctive features of the Wei Lai is its use of approximately 8,000 sensors distributed throughout the ship. These sensors monitor equipment conditions and environmental elements while collecting critical scientific data for oceanographic research and technology validation. Additionally, the ship is equipped with a specialized submersible release pool located amidships, allowing for the direct deployment of deep-sea submersibles and autonomous underwater vehicles into the water without the need for external cranes or davits. The Wei Lai’s operational schedule is fully booked through the end of 2027, with its main focus on supporting tests and missions for deep-sea exploration apparatus. The vessel will also assess the performance of environmental protection systems and intelligent instruments, while continuously being upgraded with domestically developed technologies as part of China’s broader science and technology program for deep-sea exploration and advancements in shipbuilding. Overall, the Wei Lai serves as a multifunctional research platform capable of conducting complex tasks in deep-sea oceanographic surveys and testing new marine exploration equipment. Its design facilitates comprehensive trials of cutting-edge ship technologies, with the data collected aimed at improving equipment performance and functionality before they are widely deployed for commercial or scientific purposes. By acting as a testbed for innovative marine technologies, the vessel positions China at the forefront of deep-sea exploration capabilities and highlights the country’s commitment to technological self-sufficiency in the maritime sector.

Naval & Littoral Specifications
Crew 20
Beam 20.00 m
System
Alternative Designation Wei Lai Class
Type Deep-Sea Research Vessel
Builder Shanghai Ship Research and Design Institute
Crew 20 ea
Researchers and Equipment Operators 60 ea
Dimensions
Length 111 m
Height INA
Beam 20 m
Draft INA
Displacement, Full Load 7,000 tons
Propulsion System
Engine Name INA
Engine Type The vessel is powered by four diesel generators and equipped with six propellers.
Engine Power INA
Maximum Speed 28 km/h
Cruise Speed 22 km/h
Maximum Range 10,000 nautical miles
Endurance 60 days without requiring resupply
Protection
Hull Steel
Countermeasures INA
NBC Water Washdown System Yes
Details
Country of Origin China
Category Special Purpose Ships
Naval > Special Purpose Ships
Filter Label
W
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
111 m
Width
20 m
Height
Weight
7000000 kg
Operators (1)
China
