Santa Cruz Class (TR-1700 Class) Argentinian Diesel-Electric Patrol Submarine

The TR-1700 (Santa Cruz) is a class of diesel-electric patrol submarines built by Thyssen Nordseewerke for the Argentine Navy in the 1980s, with two submarines completed. These ships are amongst the largest submarines built in Germany since World War II and are among the fastest diesel-electric submarines in the world. ARA San Juan was lost on 17 November 2017, leaving ARA Santa Cruz as the only remaining submarine of this class. The original 1977 plan called for six boats, two TR-1700s built in Germany by Thyssen Nordseewerke, two in Argentina by Astillero Domecq Garcia, and two smaller TR-1400s also built in Argentina. The final agreement in 1982 was modified to six TR-1700s, with the last four to be built in Argentina. The TR-1700s to be built in Argentina were considered for an upgrade to a nuclear submarine using INVAP's CAREM reactor, which began development at that time. The nuclear submarine project never came to fruition, despite later attempts to revive it. The submarine was designed by Thyssen and its features include high underwater speed, endurance (for a diesel submarine), and survivability. The boat's four MTU diesel engines, four generators, and Siemens electric motor can propel it at speeds up to 25 knots (46 km/h; 29 mph). Eight 120-cell batteries are installed on each boat. They have a diving depth of 300 m (980 ft). Normal endurance of these boats is 30 days with an extended range up to 70 days. These boats are equipped to accept a Deep Submergence Rescue Vehicle (DSRV). Armaments include six bow 533 mm (21 in) torpedo tubes and 22 SST (Special Surface Target) or Mark 37 torpedo. The automatic torpedo reload system can reload the tubes in 50 seconds. Thyssen proposed the TR1700A for the Australian Collins-class submarine program. The proposed design had a reworked pressure hull, was six meters longer, and half a meter wider than the TR-1700s built for Argentina. It lost to the Type 471 from Kockums, an enlarged Västergötland-class submarine. The first two submarines were delivered on schedule in 1984–85. The remaining four built in Argentina were suspended due to the Argentinean economic crisis of the 1980s. In 1996 work completely ceased on ARA Santa Fe at 70% (or 52%) completion while ARA Santiago del Estero was only 30% complete. After attempts to complete and sell the boats to Taiwan failed, they were cannibalized, along with the parts for the fifth and sixth units, to support the continued operations of the first two submarines. Santa Cruz received its mid-life modernization at Arsenal de Marinha, Rio de Janeiro Brazil between September 1999 and 2001. The work involved the replacement of the engines, batteries, and sonar. Her sister boat San Juan entered the Astillero Domecq Garcia shipyard to receive her refit in 2007; she completed refit in 2013. In September 2010, it was revealed that the Ministry of Defense was conducting feasibility studies to decide if ARA Santa Fe (S-43) should be completed. The decision should be made sometime after completing the mid-life modernization of ARA San Juan (S-42). The estimated cost of completing Santa Fe was $60 million. On 17 November 2017, the ARA San Juan was reported missing; reports of a fire at the time were denied by the Argentine Navy. A year after that, on 17 November 2018, private company Ocean Infinity (appointed by the Argentine Government) announced that they successfully located the wreck, at 900 metres depth and 500 km from Comodoro Rivadavia.
