New Holland TN60A Italian 4WD Tractor
New Holland TN60A
Trailer
Other
Basic Information
Name
New Holland TN60A Italian 4WD Tractor
Designation
New Holland TN60A
Alternate Designation
New Holland TN60A
Equipment Type
Trailer
Manufacturer
New Holland
Date of Introduction
2004
Description
New Holland TN60A Italian 4WD Tractor.
Ground Specifications
Crew
1
Engine
3-Cylinder Diesel (55 hp)
Variants
TN60A
ROPS Variant
TN60DA
Cab Variant
TN60SA
Super steer Variant
System
Alternative Designation
New Holland TN60A
Type
Tractor
Manufacturer
New Holland
Crew
1 ea
Attachments
Front-End Loader
Dimensions
Length
385 cm
Width
170 cm
Wheelbase
78.9 cm
Height
241 cm
Weight
5,400 kg
Automotive
Engine Name
New Holland; Name: INA
Engine Type
3-Cylinder, Liquid-Cooled Diesel
Engine Power
55 hp [41.0 kW]
Torque
148 lb-ft [200.7 Nm]
Torque RPM
1,400 RPMs
Fuel Capacity
87.1 L
Fuel User per Hour
11.4 Litters per hour
Starter Volts
12 Volts
Transmission
constant mesh with mechanical shuttle
Gears
8 forward and reverse
Clutch
280mm dry cerametallic plate
Hydraulics
Type
Open Center
Pressure
2755 psi [190.0 bar]
Valves
1-4
Pump Flow
12.4 gpm [46.9 lpm] or 16.9 gpm [64.0 lpm] (optional)
Steering Flow
9.2 gpm [34.8 lpm] (with power shuttle)
Front-End Loader
Type
New Holland 32LC
Length
INA
Height (to Pin)
325 cm
Weight
362 kg (without bucket)
Clearance, Dumped Bucket
243 cm
Dump Reach
96 cm
Dump Angle
53 deg
Rollback Angle
38 deg
Breakout Force (Lift)
1769 kg
Lift to Full Height (at 800 mm)
1179 kg
Protection
Hull Armor
No Protection from small arms and shell splinters
Applique Armor
No
Mine Clearing
No
NBC Protection
No
Smoke Equipment
No
Details
Country of Origin
Italy
Category
Tractors
Land > Engineer Systems > Tractors
Filter Label
N
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
3.85 m
Width
1.7 m
Height
2.41 m
Weight
5400 kg
Operators (2)
Eastern Europe
Northern Europe
