AMN-590951 (Spartak) Russian 4x4 Mine Resistant Ambush Protected (MRAP)
AMN-590951
Mine-Resistant Ambush Protected (MRAP)
Other
Basic Information
Name
AMN-590951 (Spartak) Russian 4x4 Mine Resistant Ambush Protected (MRAP)
Designation
AMN-590951
Alternate Designation
AMN-590951; Spartak; VPK-Ural
Equipment Type
Mine-Resistant Ambush Protected (MRAP)
Manufacturer
Military Industrial Company (VPK)
Date of Introduction
2022
Description
AMN-590951 (Spartak) Russian 4x4 Mine Resistant Ambush Protected (MRAP)is an upgraded variant of the VPK-Ural vehicle named after the company responsible for manufacture.
Ground Specifications
Crew
10
Engine
Turbocharged Diesel (312 hp)
NBC Protection
Yes
Max Speed
100.0 km/h
Range
1000.0 km
System
Alternative Designation
AMN-590951; Spartak; VPK-Ural
Type
Mine Resistant Ambush Protected (MRAP)
Manufacturer
Military Industrial Company (VPK)
Configuration
4x4
Crew
The habitable compartment of the hull accommodates 10 seats. In its front part, there are two rows of seats for the driver and three passengers, facing forward in the direction of travel. Access to these places is provided by its own doors in the sides. Six more seats are installed in the stern along the sides; boarding is carried out through the stern door.
Dimensions
Length
6.5 m
Width
2.5 m
Height
2.8 m
Weight, Curb
14.5 tons
Automotive
Engine Name
INA
Engine Type
Turbocharged Diesel
Engine Power
312 hp
Maximum Range
1,000 km
Maximum Speed
100 km/h
Amphibious
No
Gradient
60%
Fording
INA
Main Weapon System
Note
Armament is the Kord 12.7 mm machine gun enclosed in a protected armor box for the gunner's safety.
Protection
Armor
A welded armored hull with an engine compartment and a total volume to accommodate the crew and passengers is used. Some of the hull units are covered with additional armor sheets. The frontal projection of the habitable compartment of the hull is protected from 14,5 mm bullets; other projections can withstand fire from 12,7 mm systems. The engine compartment and chassis components are protected against armor-piercing incendiary 7,62 mm bullets.
Applique Armor
Available
Mine Protection
Mine protection is provided in the form of an armored V-shaped bottom. Resistance to explosion of 8 kg of TNT under a wheel or body is declared.
NBC Protection
Yes
Smoke Equipment
Yes
Details
Country of Origin
Russia
Category
Mine-Resistant Ambush Protected (MRAP)
Land > Infantry Vehicles > Mine-Resistant Ambush Protected (MRAP)
Filter Label
A
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
6.5 m
Width
2.5 m
Height
2.8 m
Weight
14500 kg
Operators (1)
Russia
