Type 051G Class (Luda III Class) Chinese Destroyer
Type 051G
Destroyer
Other
Basic Information
Name
Type 051G Class (Luda III Class) Chinese Destroyer
Designation
Type 051G
Alternate Designation
Type 051G; Luda III Class
Equipment Type
Destroyer
Manufacturer
—
Date of Introduction
1991
Description
The Type 051G Class (Luda III Class) Chinese Destroyer was an improved variant that the last two ships, Zhanjiang and Zhuhai, were completed too. They were equipped with Type 354 3-D air and surface search radar. Four twin YJ-8 launchers replaced the HY-1/HY-2 launchers. The Soviet sonar was replaced by French DUBV-23 search sonar and DUBV-43 variable depth sonar (VDS). Zhuhai was modified in 1999. The Soviet 130 mm guns were replaced by 100 mm (4 in) guns, derived from French Creusot-Loire Compact, with automated reloaders. An HQ-7 SAM launcher replaced the "X" turret, as on the Type 051DT. Zhuhai was similarly modified. Zhanjiang and Zhuhai were equipped with the ZKG-4A and ZKG-4B combat data systems respectively. The Type 051G was also the first Chinese ship to deploy the YU-7 lightweight torpedo and the Italian 40 mm (1.6 in) anti-aircraft gun. The Type 051G was part of the Luda III class, and later the Luda IV class. Note: There are no longer any Type 051 Class, Luda II Class, Type 051D Class, Type 051Z Class, or Type 051DT Class Chinese Destroyers left in active service.
Naval & Littoral Specifications
Crew
280
Beam
12.80 m
Draft
4.60 m
Variants
Zhanjiang
Commissioned: 1991
Fleet: South Sea Fleet
Zhuhai
Commissioned: 1991
Fleet: South Sea Fleet
System
Alternative Designation
Type 051G; Luda III Class
Type
Destroyer
Builder
Luda Shipyard
Zhonghua Shipyard
Dalian Shipyard
Crew
280 ea
Dimensions
Length
132 m
Beam
12.8 m
Draft
4.6 m
Displacement, Full Load
3,670 tons
Propulsion System
Engine Name
INA
Engine Type
2 steam turbines
Engine Power
72,000 shp (53,700 kW)
Maximum Range
2,970 miles
Maximum Speed
32 knots (59 km/h)
Endurance
INA
Gun Weapon Systems
Gun Weapon System #1: System
Name
1 x Canon de 100mm Naval Gun
Type
Naval Gun
Caliber
100 mm
Manufacturer
GIAT
Length
INA
Barrel Length
55 calibres
Weight
22 metric tons
Crew
2 (modèle 68) ; later version entirely automatic
Elevation
29°
Traverse
40°
Rate of Fire
78 round/min
Muzzle Velocity
870 m/s
Effective Firing Range
17,000 m (elevation 40°)
Maximum practical range:
6,000 m against aerial targets
12,000 m against surface targets
Gun Weapon System #1: Ammunition
Type
Rifle
Caliber
100 mm
Cartridge
100 x 700mm .R
Basic Load
INA
Gun Weapon System #2: System
Name
DARDO
Type
Close-In Weapon System (CIWS)
Quantity
1 x DARDO Close-In Weapon System (CIWS)
Length
INA
Diameter
Mount ring: 1.7 m
Working circle: 2.902 m
Height
Enclosed turret: 2.4 m
Type A mount: 1.3 m
Type B mount: 0.92 m
Weight
Complete gun mount (less ammo): 5,500 kg
Complete round (HE): 4.05 kg
Barrels
2 × Breda-built Bofors-40 mm L/70
Elevation
Minimum −13°
Maximum +85°
speed: 60°/s (70°/s Fast Forty)
Traverse
Full 360° traverse, speed: 90°/s (100°/s Fast Forty)
Rate of Fire
2 × 300 round/min
2 × 450 round/min (Fast Forty)
Maximum Firing Range
AA with HE: 8,700 m (9,500 yd)
Effective Firing Range
HE round: 4,000 m (4,400 yd)
Feed System
Magazine:
736 HE rounds (444 Type B mount)
Dual feed mechanism with 736 HE and 200 APFSDS rounds (Fast Forty)
Gun Weapon System #2: Ammunition
Type
Rifle
Caliber
40 mm
Shell
INA
Basic Load
INA
Missile Weapon Systems
Missile Weapon Systems #1: Missile Launcher
Name
YJ-8 Launchers
Type
Missile Launcher
Quantity
4 x twin YJ-8 Launchers
Missile Weapon Systems #1: Missile
Type
YJ-8 Missile
Type
Surface-launched subsonic anti-ship cruise missile.
Length
5.81 m
Weight
815 kg
Warhead Weight
165 kg
Engine
Rocket
Propellant
Solid Rocket
Operational Range
42 km
Flight Altitude
5-7 m
Speed
Mach 0.9
Guidance System
Inertial navigation/active radar homing terminal guidance
Missile Weapon Systems #2: Missile Launcher
Name
HQ-7 SAM Launcher
Type
Missile Launcher
Elevation
INA
Traverse
INA
Radar
Type 360S E/F-band Doppler radar
Radar Detection Range
18.4 km
Combat Management System
ZJK-4 (Thomson-CSF TAVITAC) combat management system.
Note
The system is capable of processing up to 30 targets, and tracking 12 targets simultaneously.
Missile Weapon Systems #2: Missile
Name
HQ-7
Type
Short-range air defense missile.
Length
3 m
Diameter
0.156 m
Wingspan
0.55 m
Weight
84.5 kg
Operating Altitude
30–5,000 m
Maximum Operating Range
12 km
Minimum Operating Range
500 m
Speed
Mach 2.3 (750 m/s)
Guidance System
Command + electro-optical tracking
Warhead
HE-FRAG with proximity fuse
Torpedo Weapon Systems
Torpedo Launcher
Name
Yu-7 Torpedo Tubes
Quantity
INA
Torpedo
Name
Yu-7 torpedo
Type
Torpedo
Length
2.7 m
Diameter
324 mm
Weight
235 kg
Warhead
high explosive
Warhead Weight
45 kg
Effective Firing Range
14.1 km
Propellant
Otto fuel II
Maximum Depth
400 m
Speed
>45 kn (83 km/h)
Guidance System
active / passive acoustic homing
Steering System
CIACIO-S seeker
Onboard Aviation Facilities
Aviation Facilities
No
Aircraft Carried
No
Fire Control System
FCS Name
INA
Computerized FCS
See Weapon Systems
Combat Data System #1
ZKG-4A
Combat Data System #2
ZKG-4B
Radar Systems
Name
Type 354 radar
Type
3-D air and surface search radar
Alternate Designation
MX902
H/LJQ-354
Proliferation
Type 354 Radars are one of the most widely deployed air and surface search naval radars in Chinese service. The Type 354 was predominantly found on major People's Liberation Army Navy (PLAN) surface combatants such as the Luda class destroyer and Jianghu class frigate in the 1980s and 1990s. By 2006 it was slowly being replaced in favour of the Type 360 radar, which in turn, itself being replaced by Type 364 radar for new vessels.
Frequency
G/H band
Beam
1.2 × 5 deg
Pulse Width
4 μs
Polarisation
linear
Beam width
1.20 (horizontal); 1.30 (vertical)
PRF
400 or 800 Hz
Scan Rate
4–10 rpm
Resolution
800 m (range); 1.30 (azimuth)
Range
more than 93 km on aircraft with RCS of 10 m2
Sonar Systems
Search Sonar
1 x DUBV-23 search sonar
Depth Sonar
1 x DUBV-43 variable depth sonar (VDS)
Protection
Active Protection System
See Weapon Systems
Countermeasures
INA
NBC Water Washdown System
Yes
Details
Country of Origin
China
Category
Naval
Naval
Filter Label
T
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
132 m
Width
—
Height
—
Weight
—
Operators (1)
China
