Shahpar II Pakistani Unmanned Aerial Vehicle (UAV)
Shahpar II
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Shahpar II Pakistani Unmanned Aerial Vehicle (UAV)
Designation
Shahpar II
Alternate Designation
Shahpar II
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
NESCOM
Date of Introduction
2015
Description
The Shahpar II Pakistani Unmanned Aerial Vehicle (UAV) is a medium-range tactical UAV System with autonomous take-off and landing. It can carry various types of payloads integrated for reconnaissance and day & night surveillance. Other features include accurate lateral, and longitudinal trajectory control, mission planning, management & control, geo-referencing & geo pointing for terrestrial targets.
Air & Air Defense Specifications
Engine
4 - Cylinder, 4 stroke piston (100 hp)
Max Speed
180.0 km/h
Range
250.0 km
Endurance
7.00 hrs
Service Ceiling
5000 m
Wingspan
6.60 m
Payload Capacity
50 kg
System
Alternate Designation
Shahpar II
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
NESCOM
Autonomy
Autonomous, GPS Based (manual control channel available)
Crew
Unmanned
Payload Capacity
50 kg
Reconnaissance Equipment
Various types of payloads integrated for reconnaissance and day & night surveillance
Takeoff
Autonomous Takeoff
Landing
Autonomous Landing
Dimensions
Length
4.2 m
Wingspan
6.6 m
Height
INA
Empty Weight
INA
Maximum Takeoff Weight
480 kg
Automotive
Engine Name
Rotax 912 ULS
Engine Type
4 - Cylinder, 4 stroke piston
Engine Power
100 hp
Maximum Speed
180 km/h
Cruising Speed
150 km/h
Service Ceiling
5,000 m
Maximum Distance
250 km Data Link Range
Endurance
7 hours
Image Sources
Notes
https://www.rt.com/news/pakistan-deploys-domestic-drones-293/; https://aminoapps.com/c/military-amino/page/item/nescom-burraq-ucav/1Jam_jzVsrI1vdNwrG5G36gke4rYNmkPle8; https://threadreaderapp.com/thread/1476398669423431691.html; https://www.reddit.com/r/MilitaryPorn/comments/28y7oo/pakistans_first_indigenous_armed_drone/;
Details
Country of Origin
Pakistan
Category
UAVs
Air > UAVs
Filter Label
S
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
4.2 m
Width
6.6 m
Height
—
Weight
480 kg
Operators (1)
Pakistan
