BК-9 Class Russian Fast Attack Craft (Assault Boat)
BК-9 Class
Patrol Boat
Other
Basic Information
Name
BК-9 Class Russian Fast Attack Craft (Assault Boat)
Designation
BК-9 Class
Alternate Designation
BК-9 Class
Equipment Type
Patrol Boat
Manufacturer
Kalashnikov Concern JSC
Date of Introduction
2015
Description
The BК-10D Class Russian Fast Attack Craft (Assault Boat) is designed for a range of special tasks in forward-deployment areas and operational locations. Its primary purposes include: - Rapidly delivering landing-assault combat units to the shore or transporting inspection teams to detained ships. - Providing fire support for special units or marine operations. - Conducting patrol activities, including sabotage and anti-sabotage missions. The boat features a perimeter protected by removable armored sheets. Additionally, there are modifications available for medical purposes and for use by divers.
Naval & Littoral Specifications
Crew
2
Beam
3.07 m
Draft
0.65 m
System
Alternative Designation
BК-9 Class
Type
Fast Attack Craft (Assault Boat)
Builder
Kalashnikov Concern JSC
Crew
2 ea
Passengers
8 ea
Dimensions
Length
9.9 m
Height
3.20 m
Beam
3.07 m
Draft
0.65 m
Displacement, Full Load
7.8 tons
Propulsion System
Engine Name
INA
Engine Type
2 x Diesel Engines
Engine Power
2 x 379 hp
Maximum Range
644 km
Maximum Speed
40 knots (74 km/h)
Endurance
24 hours
Main Weapon System
Note
4 x Machine gun, calibre 7.62 mm; 1 x Machine gun, calibre 12.7 mm; 1 x Grenade launcher, 40 mm.
Protection
Hull
Steel
NBC Water Washdown System
No
Details
Country of Origin
Russia
Category
Small Boats
Naval > Small Boats
Filter Label
B
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
9.9 m
Width
3.07 m
Height
3.2 m
Weight
7800 kg
Operators (1)
Russia
