Kian-1 Iranian Unmanned Aerial Vehicle (UAV)
Kian-1
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Kian-1 Iranian Unmanned Aerial Vehicle (UAV)
Designation
Kian-1
Alternate Designation
Kian-1
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
—
Date of Introduction
2019
Description
The Kian-1 Iranian Unmanned Aerial Vehicle (UAV) mission is to measure air defense equipment, use it as a flying target, and also can be used as a suicide attack UAV; it is made in small dimensions and equipped with a microjet engine.
Air & Air Defense Specifications
Engine
The Kian-1 uses solid-fuel boosters to start the flight and reach the initial speed required to start the jet engine.
Max Speed
480.0 km/h
Range
1000.0 km
Service Ceiling
5000 m
Wingspan
2.00 m
Payload Capacity
30 kg
Variants
Kian-2
Kian 2 was unveiled in September 2019. Kian is made for various missions; one of its missions is to destroy the intended targets in to-the-point and suicide missions.
It can destroy targets far beyond the country's borders with high flight continuity.
This drone is made with a wingspan of about 3.5 to 4 meters and a length of about 4.5 meters. Larger dimensions and thicker wings are suitable for flying at subsonic speeds and allow it to carry much more fuel. The operational range of this drone is more than 1,000 km.
It is also possible to install some kind of enemy radar wave reception system inside this drone, which can make it a suitable option for the anti-radar role. It uses two air inlets with an advanced design to match the fuselage and its sides. This drone is a Delta wing type that provides desirable flight characteristics for it at high speeds.
System
Alternate Designation
Kian-1
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
INA
Payload Capacity
30 kg
Dimensions
Length
INA
Height
INA
Wingspan
2.0 m
Maximum Takeoff Weight
INA
Automotive
Engine Name
INA
Engine Type
The Kian-1 uses solid-fuel boosters to start the flight and reach the initial speed required to start the jet engine.
Engine Power
INA
Maximum Speed
480 km/h
Maximum Range
1,000 km
Service Ceiling
5,000 m
Endurance
INA
Armament
Note
1 x Impact-Detonated warhead of unkown weight and composition.
Details
Country of Origin
Iran
Category
UAVs
Air > UAVs
Filter Label
K
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
—
Width
2 m
Height
—
Weight
—
Operators (1)
Iran
