Bayraktar DIHA Turkish Unmanned Aerial Vehicle (UAV)

Bayraktar DIHA

VTOL Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Bayraktar DIHA Turkish Unmanned Aerial Vehicle (UAV)
Designation
Bayraktar DIHA
Alternate Designation
Bayraktar DIHA
Equipment Type
VTOL Unmanned Aerial Vehicle (UAV)
Manufacturer
Baykar
Date of Introduction
2019
Description

The Bayraktar DIHA Turkish Unmanned Aerial Vehicle (UAV) is a Mini Tactical UAV class aircraft capable of carrying out activities for reconnaissance and intelligence missions. The vehicle is capable of automatic cruise, autonomous take-off, autonomous landing and semi-autonomous cruise flight. Bayraktar DIHA, after taking off with electric motors, will switch to cruise flight mode and only fuel engine is going to be active in cruise flight mode. There are three options for landing: vertical landing, landing on fuselage and parachute landing. The aircraft has a flight control system that can perform automatic route tracking, target tracking, circling and return-to-home modes.

Air & Air Defense Specifications
Max Speed 80.0 km/h
Range 150.0 km
Endurance 12.00 hrs
Service Ceiling 4572 m
Wingspan 5.00 m
Payload Capacity 5 kg
System
Alternate Designation Bayraktar DIHA
Type Vertical Take-Off and Landing (VTOL) Unmanned Aerial Vehicle (UAV)
Manufacturer Bayraktar
Autonomy Fully Autonomous with Sensor Fusion Assisted
Crew Unmanned
Payload Capacity 5 kg
Camera Electro-Optical (EO) Camera Module; Infrared (IR) Camera Module
Launching System Vertical Take-Off and Landing (VTOL)
Recovery System Vertical Take-Off and Landing (VTOL)
Dimensions
Length 1.5 m
Wingspan 5.0 m
Height INA
Maximum Takeoff Weight 50 kg
Automotive
Engine Name INA
Engine Type INA
Engine Power INA
Maximum Speed 80 km/h
Cruising Speed 92 km/h
Service Ceiling 4,572 m
Maximum Range 150 km
Endurance 12 hours
Details
Country of Origin Turkey
Category UAVs
Air > UAVs
Filter Label
B
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.5 m
Width
Height
Weight
50 kg
Operators (1)
Turkey
