Go Jun Bong Class South Korean Amphibious Landing Ship
Go Jun Bong Class
Amphibious Landing Ship
Other


Basic Information
Name
Go Jun Bong Class South Korean Amphibious Landing Ship
Designation
Go Jun Bong Class
Alternate Designation
Go Jun Bong Class
Equipment Type
Amphibious Landing Ship
Manufacturer
—
Date of Introduction
1994
Description
Go Jun Bong Class LST is an Amphibious Landing Ship class of the Republic of Korea Navy. Go Jun Bong class LST is based on the design of the LST-542 class LST, and thus its exterior is very similar to the Un Bong class LST. The ship is designed to land multiple personnel, tanks and equipment simultaneously with doors and ramps placed on both the stern and bow of the ship, unlike the Un Bong class LST which only has doors on the bow. It is also equipped with a turn table, saving time when loading or landing vehicles. There is also a ramp for moving trucks up to the deck, and multiple elevators for rapid cargo loading.
Ground Specifications
Crew
169
Variants
Go Jun Bong
Commissioned: 1994
Status: Active
Bi Ro Bong
Commissioned: 1998
Status: Active
Hyang Ro Bong
Commissioned: 1999
Status: Active
Sung In Bong
Commissioned: 1999
Status: Active
System
Alternative Designation
Go Jun Bong Class
Type
Amphibious Landing Ship
Builder
Hanjin Industrial Shipbuilding, Masan, South Korea
Crew
169
Troops
200
Dimensions
Length
112.50 m
Beam
15.30 m
Draft
3.00 m
Displacement, Standard
1,900 tons
Displacement, Full Load
4,278 tons
Propulsion System
Engine Name
2 x SEMT-Pielstick type 16 PA6 V280
Engine Type
Diesel Engines
Engine Power
12,800 total bhp
Fuel Capacity
INA
Maximum Range
4,500 nm at 12 knots
Maximum Speed
16 knots
Main Weapon System
System #1
Name
Bofors 40 mm gun
Type
Anti-Aircraft Autocannon
Caliber
40 mm
Quantity
4 x Bofors 40 mm Anti-Aircraft Autocannon
Length
6.5 m
Barrel Length
2.2 m
Width
1.8 m
Height
1.9 m
Weight
1,981 kg
Barrels
1 or 2
Traverse
360°
Rate of Fire
120 round/min
Muzzle Velocity
881 m/s
Maximum Firing Range
7,160 m
System #1, Ammunition
Type
Rifle
Caliber
40mm
Shell
40×311mmR
Basic Load
INA
System #2
Name
M61 Vulcan
Type
Autocannon
Caliber
20 mm
Quantity
2 x M61 Vulcan 20mm Autocannons
Barrels
6-barrel (progressive RH parabolic twist, 9 grooves)
Action
Hydraulically operated, electrically fired, rotary cannon
Rate of Fire
6,000 rounds per minute
Muzzle Velocity
1,050 m/s
Feed System
Belt or linkless feed system
System #2, Ammunition
Type
Rifle
Caliber
20 mm
Cartridge
20×102 mm
Basic Load
INA
Fire Control Systems
Optronic Gun Fire Control System
1 x Selenia NA-18 optronic gun fire control
Vulcan Fire Control System
2 x Mark 90 Vulcan fire control
Radar Systems
Surface Search Radar
1 x Raytheon AN/SPS-64(V)9 surface search
Navigation Radar
1 x Raytheon AN/SPS-64(V)6 navigation radar
Aviation Facilities
Helicopters
1 × UH-60 helicopter
Protection
Radar Intercept
1 x radar intercept
NBC Water Washdown System
Yes
Chaff Launcher
1 x RBOC chaff launcher
Details
Country of Origin
South Korea
Category
Naval
Naval
Filter Label
G
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
112.5 m
Width
—
Height
—
Weight
—
Operators (1)
South Korea
