Kamorta Class (Project 28 Class) Indian Corvette

Kamorta Class

Corvette
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Kamorta Class (Project 28 Class) Indian Corvette
Designation
Kamorta Class
Alternate Designation
Kamorta Class; Project 28 Class
Equipment Type
Corvette
Manufacturer
Garden Reach Shipbuilders & Engineers
Date of Introduction
2014
Description

The Kamorta Class (Project 28 Class) of Indian corvettes are a series of anti-submarine warfare ships currently in service with the Indian Navy. The platform and key internal systems of these corvettes have been designed and built domestically. The design is believed to be a collaborative effort between the Indian Navy's Directorate General Naval Design Surface Ship Group (DGND SSG) and the in-house design team at Garden Reach Shipbuilders & Engineers. To enhance stealth capabilities, the corvettes have implemented measures to reduce acoustic, magnetic, infrared (IR), and radar cross-section signatures. They are equipped with raft-mounted main reduction gear systems provided by DCNS/WIL. The third and fourth ships in the class feature composite superstructures supplied by Saab Kockums, which help to reduce the vessels' top weight. These corvettes are named after islands in the Lakshadweep archipelago. The Kamorta-class is intended to succeed the Kora class in terms of precedence and the Abhay class in terms of role.

Naval & Littoral Specifications
Crew 220
Beam 12.80 m
Draft 3.72 m
Variants
Kamorta Commissioned: 2014 Status: Active
Kadmatt Commissioned: 2016 Status: Active
Kiltan Commissioned: 2017 Status: Active
Kavaratti Commissioned: 2020 Status: Active
System
Alternative Designation Kamorta Class; Project 28 Class
Type Corvette
Builder Garden Reach Shipbuilders and Engineers
Crew Enlisted: 220; Officers: 16
Dimensions
Length 109.2 m
Height INA
Beam 12.8 m
Draft 3.72 m
Displacement, Full Load 3,500 tons
Propulsion System
Engine Name 4 x SEMT-Pielstick Kirloskar 12PA6 STC
Engine Type Diesel
Engine Power 22,030 hp
Maximum Range 4,000 n miles (7,408.0 km) (4,603.1 miles) at 12 kt (22.2 km/h) (13.8 mph)
Maximum Speed 25 kt (46.3 km/h) (28.8 mph)
Main Weapon Systems
Combat Data System 1 x BEL CMS-28. Datalinks. Rukmini satcom with Orbit terminals.
Missile System
Surface-to-Air Missiles (SAM) 16-cell VLS system (fitted for but not currently installed).
Gun System
Guns 1 x Oto Melara 76 mm/62 Super Rapid; 120 rds/min to 16 km (8.6 n miles); weight of shell 6 kg. 2 x AK-630M 30 mm/65; 6 barrels per mounting; 5,000 rds/min combined to 4 km. 2 x 12.7 mm MGs. 6 x 7.62 mm MGs.
Torpedo System
Torpedo Tubes 4 x Larsen & Toubro Indigenous Twin Torpedo Launchers (ITTL) (2 twin); 533 mm.
Torpedoes INA
Anti-Submarine Mortars
Note 2 x Larsen & Toubro Indigenous Rocket Launcher (RBU-6000); AFK rocket-propelled depth charges (RGB-60); range 300–6,000 m; depth 15–450 m; warhead 25 kg.
Radar Systems
Air/Surface Search Radar 1 x BEL Revathi; 3D; E/F-band.
Fire Control Radar 2 x BEL Lynx (for 76 mm); I-band.
Navigation Radar 2 x Decca Bridgemaster; I-band.
Sonar System
Sonar 1 x BEL HUMSA; hull mounted; active/passive medium frequency. 1 x Atlas Elektronik Advanced Towed Array Sonar (ACTAS) active; low frequency.
Aviation
Helicopters 1 x Chetak or 1 x Dhruv Helicopter.
Note The stern landing deck can support the operation of a single helicopter. The Kamorta Class corvettes are the first Indian Navy ships to be equipped with a rail-less helo traversing system and foldable hangar door.
Protection
Hull The Kamorta Class features a high-tensile indigenous steel hull incorporating a superstructure made of indigenous DMR 249A steel and carbon fibre reinforced plastic (CFRP) materials. The hull and superstructure are designed to achieve a low radar cross-section. The stealthier hull form is designed to deliver excellent seakeeping and manoeuvrability characteristics while also ensuring lower noise and vibration levels. The ASW corvette includes indigenous content of about 90%.
Physical Countermeasures 2 x Kavach Mod 2 chaff/flare decoy launchers. Towed torpedo decoy.
Electronic Countermeasures 1 x Sanket Mk 3. ELK-7036 CESM.
NBC Water Washdown System Yes
Details
Country of Origin India
Category Naval
Naval
Filter Label
K
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
109.2 m
Width
12.8 m
Height
Weight
3500000 kg
Operators (1)
India
