UJ-23 Topza Ukrainian Unmanned Aerial Vehicle (UAV)
UJ-23 Topaz
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
UJ-23 Topza Ukrainian Unmanned Aerial Vehicle (UAV)
Designation
UJ-23 Topaz
Alternate Designation
UJ-23 Topaz
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
UKRJET
Date of Introduction
2023
Description
The UJ-23 Topza Ukrainian Unmanned Aerial Vehicle (UAV) is a multi-purpose unmanned aircraft system with jet UAV that is able to be used at any time of day and season, in visual and adverse weather conditions and under electronic countermeasures.UJ-23 TOPAZ can perform tasks for training, intelligence, search and rescue operations for military and rescue services.
Air & Air Defense Specifications
Engine
Battery
Max Speed
800.0 km/h
Cruise Speed
600.0 km/h
Endurance
90.00 hrs
Payload Capacity
10 kg
System
Alternate Designation
UJ-23 Topaz
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
UKRJET
External crew
2 ea
Payload Capacity
10 kg
Maximum Ground Control Station performance
24/7
UASs deployment time
10 min
UASs rollup time for transportation
5 min
UAVs reflight time
3 min
Operating Temperature
- 40...+ 50 °С
Takeoff type
From launching unit in auto mode
Landing type
With parachute in auto mode
Dimensions
Length
INA
Height
INA
Wingspan
INA
Weight
INA
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Maximum radius of controlled flight
100 km
Maximum Speed
800 km/h
Cruise Speed
600 km/h
Minimal Speed
200 km/h
Maximum Altitude
6,000 m
Minimum Altitude
50 m
Endurance
90 m
Details
Country of Origin
Ukraine
Category
UAVs
Air > UAVs
Filter Label
U
Classification
Domain
Air & Air Defense
Equipment Status
Active
Operators (1)
Ukraine
