Evo II American Remote Controlled Quadcopter

EVO II

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Evo II American Remote Controlled Quadcopter
Designation
EVO II
Alternate Designation
EVO II
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Autel Robotics
Date of Introduction
2018
Description

Experience the current leading edge of video resolution with the EVO II 8K Drone from Autel. With an 8K camera payload, the EVO II 8K can capture video at up to 7680 x 4320 resolution (8000 x 6000 stills). This lets you make prints up to 100" wide, punch in, crop, and scale images with great detail, and capture stunning hi-res screenshots from your footage. The EVO II drone provides hi-end specifications and abilities well beyond videography and photography. The 7100mAh battery lets it fly for up to 40 minutes at a time, the motors can fly in Ludicrous Speed mode at up to 44.8 mph, and you can transmit HD footage back to the controller's 3.3" OLED screen from up to 5.6 miles away. While flying and tracking, 12-sensor omnidirectional obstacle avoidance is coupled with a dual-core processor and AI machine learning to let the EVO II navigate itself around the environment safely, while still getting the shot. Additional Features *Remote controller with 3.3" OLED screen *Capture 48MP hi-res stills *Record HDR video at up to Ultra HD 4K resolution *Get a clear image with phase detection autofocus *Capture action in dramatic 120 fps slow motion at up to 2K resolution *4x lossless in-camera zoom *Support for 10-bit A-LOG *Defogging mode *Foldable design for a compact and ultra-portable form factor *Battlock system to help prevent accidental battery ejections during hard maneuvers and landings *Radar feature for more environmental information while manually piloting with avoidance turned off

Variants
Evo I The Evolution of flight has arrived. EVO is a compact folding unit designed to go wherever your adventure takes you. Equipped on the front EVO offers a powerful camera on a 3-axis stabilize gimbal that records video at 4k resolution up to 60 frames per second and a recording speed up to 100mbps in an H.264 or H.265 codec. Using real-glass optics EVO captures stunning photos at 12 megapixels with a wide dynamic range for more details and color. Integrated advanced computer vision systems provide forward obstacle avoidance, rear obstacle detection and bottom sensors for more accurate landings and stable indoor flights. EVO boasts flight times up to 30 minutes with a range of 4.3 miles (7KM). Additionally, EVO offers failsafe features letting you know when the battery is low and it’s time to return to home. EVO includes a remote controller which houses a 3.3-inch OLED screen providing you with critical flight information or a live 720p HD video feed letting you see the camera view without the need for a mobile device.
System
Alternate Designation EVO II
Type Remote Controlled Quadcopter
Manufacturer Autel Robotics
Vision System Downward, Forward, Backward, Left, Right
Obstacle Sensory Range 1.6 to 131.2' / 0.5 to 40.0 m
Forward Field of View 60° (Horizontal) 80° (Vertical)
Backward Field of View 60° (Horizontal) 80° (Vertical)
Operating Frequency 2.4 GHz
Maximum Operating Distance 5.59 Miles / 9 km at 2.4 G
Battery Chemistry Lithium-Ion Polymer (LiPo)
Battery Capacity 5000 mAh
Built-In Display Size 3.3"
Photo Resolution 4:3: 8000 x 6000
Video Format 7680 x 4320 (MP4/MOV via H.264/AVC, H.265/HEVC)
Recording Media SD (up to 128 GB)
Dimensions
Length INA
Width INA
Height INA
Weight 2.62 lb / 1192 g
Automotive
Engine Name INA
Engine Type INA
Number of Rotors 4
Engine Power INA
Maximum Horizontal Speed 44.8 mph / 20 m/s
Flight Ceiling 4.35 Miles / 7000 m
Maximum Flight Time 40 Minutes
Maximum Hover Time 35 Minutes
Number of Axes 3 (Pitch, Roll, Yaw)
Details
Country of Origin United States
Category Remote Controlled Aircraft
Air > Remote Controlled Aircraft
Filter Label
E
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
Width
Height
Weight
1.19 kg
Operators (1)
United States
