Donbas Class (Project 304 Class) Ukrainian Command Ship
Donbas Class
Automated Command and Control (C2) System
Other
Basic Information
Name
Donbas Class (Project 304 Class) Ukrainian Command Ship
Designation
Donbas Class
Alternate Designation
Donbas Class; Project 304 Class
Equipment Type
Automated Command and Control (C2) System
Manufacturer
Szczecin Shipyard
Date of Introduction
1969
Description
The Donbas Class (Project 304 Class) Ukrainian Command Ship is a former Soviet repair ship that was converted to a command ship in the Ukrainian Navy, Project 304 (NATO reporting name: Amur). The ship was built on Szczecin Shipyard in Poland in 1969 for the Soviet Navy and named PM-9. "PM" is a Russian abbreviation for a repair ship and literally means a floating repair shop. As a result of the distribution of the Black Sea Fleet, PM-9 was renamed to Krasnodon. In 2001, the ship was renamed the Donbas. During service in the Ukrainian Navy, the ship has repeatedly participated in international exercises, as well as in local military floating parades and cruises.
Naval & Littoral Specifications
Crew
145
Beam
17.00 m
Draft
4.63 m
Variants
Project 304 Class (NATO: Amur Class)
13 Ships commissioned between October 1969 to March 1974
System
Alternative Designation
Donbas Class; Project 304 Class
Type
Command and Control Vessel
Builder
Szczecin Shipyard, Poland
In Service
1969-Present
Crew
145 ea
Dimensions
Length
122.0 m
Beam
17.0 m
Draft
4.63 m
Displacement, Standard
5,520 tons
Displacement, Full Load
INA
Propulsion System
Engine Name
Zgoda-Sulzer 8TAD-48
Engine Type
Diesel
Number of Engines
1
Engine Power
3,000 hp
Number of Shafts
1
Endurance
INA
Maximum Range
13,000 nmi
Maximum Speed
1 kn
Weapon Systems
Gun Weapon
Name
2 x 2M-3M Naval dual-purpose gun
Type
Naval dual-purpose gun
Caliber
25 mm
Crew
1
Barrel Length
2.0 m
Height
INA
Weight
110 kg
Barrels
2
Action
Gas-operated
Elevation
-10 / +85 degrees
Traverse
360 deg
Rate of Fire
450 rounds/min
Muzzle Velocity
900 m/s
Effective Firing Range
2,800 m
Feed System
Belt-fed (65 rd belts)
Sights
Optical
Gun Weapon Ammunition
Type
HE-FRAG, AP, Tracer, Bursting Charge
Caliber
25 mm mm
Shell
HEI-Frag, Frag-T
Shell Weight
0.644 - 0.672 kg
Basic Load
INA
Protection
Active Protection System
INA
Electronic Warfare
INA
Decoys
INA
NBC Protection
Yes
Electronics
Radar
"Don" Navigation Radar
Surface Search
"Rumb" Radio Direction Finder
Image Sources
Details
Country of Origin
Poland
Category
Special Purpose Ships
Naval > Special Purpose Ships
Filter Label
D
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
122 m
Width
17 m
Height
—
Weight
5520000 kg
Operators (3)
Russia
Ukraine
Soviet Union
