Arihant Class Indian Nuclear Ballistic Missile Submarine
Arihant Class
Nuclear-Powered Ballistic Missile Submarine (SSBN)
Other
Basic Information
Name
Arihant Class Indian Nuclear Ballistic Missile Submarine
Designation
Arihant Class
Alternate Designation
Arihant Class
Equipment Type
Nuclear-Powered Ballistic Missile Submarine (SSBN)
Manufacturer
Navy Shipbuilding Centre, Visakhapatnam
Date of Introduction
2016
Description
The Arihant Class Indian Nuclear Ballistic Missile Submarine is India’s first nuclear-powered submarine. The ship submersible ballistic, nuclear (SSBN) submarine was launched at the Indian Navy’s dockyard in Visakhapatnam, which is the headquarters of India’s Eastern Naval Command.
Naval & Littoral Specifications
Crew
95
Beam
11.00 m
Draft
15.00 m
Variants
INS Arihant
Commissioned: 2016
Status: Active
INS Arighaat
Commissioned: 2024
Status: Active
INS Aridhaman
Commissioned: 2024
Status: Active
System
Alternative Designation
Arihant Class
Type
Nuclear Ballistic Missile Submarine
Builder
Navy Shipbuilding Centre, Visakhapatnam
Crew
95 ea
Dimensions
Length
111.0 m
Beam
11.0 m
Draft
15.0 m
Displacement, Surfaced
6,000 tons
Propulsion System
Engine Name
1 x CLWR-B1 pressurized water reactor
Engine Type
The reactor consists of 13 fuel assemblies each having 348 fuel pins. The PWR consists of a huge pressure hull, a tank containing water and a reactor. It also consists of a pressure vessel built from unique steel, a control room as well as an auxiliary control room.
The propulsion plant housing the reactor is 42m long and 8m in diameter. The complete propulsion plant along with the primary, secondary, electrical and propulsion systems occupy half of the submarine. To reduce the weight of the plant, light water and enriched uranium was used as opposed to non-enriched uranium used in land-based reactors.
Engine Power
INA
Maximum Range
Unlimited except by food supplies
Maximum Speed, Surface
12–15 kn (22–28 km/h)
Maximum Speed, Submerged
24 kn (44 km/h)
Test Depth
450 m
Main Weapon System
Note
Arihant is capable of carrying all types of missiles and has underwater ballistic missile launch capability. It can carry 12 x K-15 SLBMs that can be launched even under ice caps.
The K-15 missiles are 10.4m long and have a diameter of 1m. The 6.3t missiles can carry a 5t nuclear warhead targeted 750km away. The K-15 missiles, however, will be replaced later by the 3,500km range K-X missiles.
Apart from the K-15s, the submarine will carry a range of anti-ship and land-attack cruise missiles and torpedoes.
Sonar Systems
Note
Arihant is fitted with a combination of two sonar systems – Ushus and Panchendriya. Ushus is state-of-the-art sonar meant for Kilo Class submarines. Panchendriya is a unified submarine sonar and tactical control system, which includes all types of sonar (passive, surveillance, ranging, intercept and active). It also features an underwater communications system.
Protection
Hull
Double-hulled. Seven W/T compartments.
Physical Countermeasures
Bharat Dynamics Limited C-303 torpedo decoy system.
Electronic Countermeasures
ESM: Radar warning.
NBC Water Washdown System
Yes
Image Sources
Note
https://lens.google.com/search?ep=gisbubb&hl=en&re=df&p=AbrfA8pQw_x4OOLQbq_07mYJ5Em2jRQmvBuyAe6kDJWZ8JA6HRym3sXFihYSLlZecAuKe94YtIkJlEfJpAWYr2iqc6Z45R3yXOGUipRtTBRV6ApZ0gKrFdJxy-CptpEvFxKCopNEenXaa5X34T7fxFDXVxq0ohBiTy8KyXIi78ZPGdHNjexr960RIgvQUZoTnKN1PI3HJf63daDA1A%3D%3D#lns=W251bGwsbnVsbCxudWxsLG51bGwsbnVsbCxudWxsLG51bGwsIkVrY0tKR1kzT0dObU1tWTJMV0ZrTUdJdE5EVmlOUzA0TVRjMUxXSmhPR1JoT1ROaU1UQm1NaElmVVY5dU5uSkRWRkE0UTNkWGMwNXBYM3AxVm1GWlRWVk1WM1p2Ums1Q2F3PT0iLG51bGwsbnVsbCxudWxsLG51bGwsbnVsbCxudWxsLG51bGwsWyJkZmE5MjkwMi1mN2EyLTRkYjQtODYzYS1mZDViNmU0NTM4ZjgiXV0=; https://www.navalnews.com/tag/arihant/; https://nationalinterest.org/blog/buzz/hatch-was-left-open-3000000000-submarine-you-know-what-happened-next-208923; https://www.scmp.com/week-asia/politics/article/3282628/india-boosts-naval-power-growing-nuclear-submarine-fleet-it-closing-gap-china
Details
Country of Origin
India
Category
Submarines
Naval > Submarines
Filter Label
A
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
111 m
Width
11 m
Height
—
Weight
6000000 kg
Operators (1)
India
