BLA-06 Russian Unmanned Aerial Vehicle (UAV)
BLA-06
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
BLA-06 Russian Unmanned Aerial Vehicle (UAV)
Designation
BLA-06
Alternate Designation
BLA-06; Aist (Stork)
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
NII Kulon, Moscow, Russia
Date of Introduction
2003
Description
The BLA-06 (bespilotnyi letatelnyi apparat, or pilotless aerial vehicle) is an unmanned aerial vehicle (UAV) designed for military and civilian reconnaissance operations. The UAV is the first of Russian design with retractable landing gear, enabling it to operate from normal airfields or roads.
Air & Air Defense Specifications
Engine
2 x piston
Max Speed
250.0 km/h
Endurance
12.00 hrs
Wingspan
8.00 m
System
Alternate Designation
BLA-06; Aist (Stork)
Type
Reconnaissance Unmanned Aerial Vehicle (UAV)
Manufacturer
NII Kulon, Moscow, Russia
Positioning Accuracy
50 m
Takeoff and Landing Run
150 m
Turret
SON-100 electro-optical turret
Radar
X-band synthetic aperture side-looking radar
TV Camera
Yes
Thermal Imaging Camera
Yes
Gas Analyzer
Available
Landing Gear
The UAV is the first of Russian design with retractable landing gear, enabling it to operate from normal airfields or roads.
Dimensions
Length
4.7 m
Wingspan
8.0 m
Weight
500 kg
Automotive
Engine Name
INA
Engine Type
2 x piston
Engine Power
INA
Maximum Speed
250 km/h
Range
250 km (Communications ) at high altitude
Maximum Celling
6,000 m
Minimum Ceiling
100 m
Endurance
12 hours
Details
Country of Origin
Russia
Category
UAVs
Air > UAVs
Filter Label
B
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
4.7 m
Width
—
Height
—
Weight
500 kg
Operators (1)
Russia
