Liebherr FKL German All-Terrain Crane
Liebherr FKL
All-Terrain Crane
Other
Basic Information
Name
Liebherr FKL German All-Terrain Crane
Designation
Liebherr FKL
Alternate Designation
Liebherr FKL
Equipment Type
All-Terrain Crane
Manufacturer
—
Date of Introduction
1991
Description
The Liebherr Fahrzeugkran Leicht (FKL), or Light Mobile Crane was specially designed to meet requirements of the Bundeswehr (German military). Sometimes it is referred as the FKL 10 due to its lifting capacity of 10 t. Production order was awarded to Liebherr in 1990 after severe competition. A total of 251 units were delivered to the German military alongside 208 larger and more powerful Liebherr FKM cranes with lifting capacity of 20 t. Deliveries of the FKL began in 1991 and were completed in 1994. This crane is used by all branches of the German military, including army, navy and air force.
Ground Specifications
Crew
2
Engine
Diesel (256 hp)
Variants
Liebherr FKM
Liebherr FKM (Fahrzeugkran Mittel or Medium Mobile Crane), is a larger and more capable machine with 6x6 configuration. It has a lifting capacity of 20 t. Its rear cargo platform has a 16 t capacity. This mobile crane was also adopted by the German military. A total of 208 units were delivered. This crane has been exported to the Netherlands (27 units). Some of these cranes are fitted with armored cabs.
System
Alternative Designation
Liebherr FKL
Type
All-Terrain Crane
Crew
2 ea
Bulldozer Blade
No
Crane
Yes
Ground Penetrating Radar
No
Bucket Loader
No
Back-hoe Excavator
No
Ditch Trencher
Noi
Recovery Winch
85 m of cable.
Winch Capacity
20 tons
Maximum Lifting Capacity
10 tons
Towed Load
6.5 tons
Note
At its maximum reach the crane can lift loads with a maximum weight of 2.4 t. This crane does not requires any counterweight.
Dimensions
Length
9.22 m
Width
2.5 m
Height
3.2 m
Weight
16.1 tons
Weight with add-on Equipment
17.6 tons
Crane Length
13 m
Automotive
Engine Name
KHD F8L513
Engine Type
Diesel
Engine Power
256 hp
Cruising Range
800 km
Speed, Maximum Road
75 km/h
Speed, Average Cross
INA
Speed Maximum Swim
Not Amphibious
Gradient
60
Side Slope
20 %
Vertical Step
0.5 m
Trench
0.6 m
Fording Depth
1.2 m
Protection
Hull Armor
INA
Applique Armor
No
Mine Clearing
No
Self-Entrenching Blade
No
NBC Protection
INA
Smoke Equipment
No
Image Sources
Details
Country of Origin
Germany
Category
Mobility
Land > Combat Support Vehicles > Mobility
Filter Label
L
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
9.22 m
Width
2.5 m
Height
3.2 m
Weight
16100 kg
Operators (1)
Germany
