Haasta Polish Unmanned Aerial Vehicle (UAV)
Haasta
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Haasta Polish Unmanned Aerial Vehicle (UAV)
Designation
Haasta
Alternate Designation
Haasta
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Military Institute of Armament Technology (WITU - Wojskowy Instytut Techniczny Uzbrojenia)
Date of Introduction
2023
Description
The Haasta Polish Unmanned Aerial Vehicle (UAV) is specifically designed to hunt low-velocity flying drones, like the Shahed type that Russia has heavily employed in Ukraine. Its primary task involves searching for combustion engine emissions. The designers boast that the UAV can penetrate air defenses, operate deep within enemy territory, and conduct intelligence, surveillance, and reconnaissance (ISR) missions. Additionally, it has the capability to operate in swarms, which can help confuse anti-aircraft defense systems.
Air & Air Defense Specifications
Engine
Hybrid (20 hp)
Max Speed
112.0 km/h
Range
30.0 km
Endurance
10.00 hrs
Wingspan
3.90 m
Payload Capacity
34 kg
System
Alternate Designation
Haasta
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
Military Institute of Armament Technology (WITU – Wojskowy Instytut Techniczny Uzbrojenia)
Payload Capacity
34.9 kg
Launching
The system is designed to be launched from an air launcher.
Landing
Lands on a skid or gliding parachute, rather than requiring traditional airport infrastructure.
Dimensions
Length
2.9 m
Height
INA
Wingspan
3.9 m
Maximum Takeoff Weight
150 kg
Automotive
Engine Name
ICE
Engine Type
Electric hybrid engine
Engine Power
20 hp
Maximum Speed
112 km/h
Maximum Range
The operating radius on paper is 30 km with standard radio, 80 km in a mesh system, or 170 km (LoS link with directional antennas). If connected to a satellite, the range is limited to fuel — with a maximum endurance of 10 hours.
Service Ceiling
INA
Endurance
10 hours
Armament
Note
A underbelly mounted 5.45mm machine gun. In the future, it may be possible to arm the design with a 7.62mm or 12.7mm UKM with ammunition belt or alternatively with two 20kg free fall bombs in fuselage.
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
H
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
2.9 m
Width
3.9 m
Height
—
Weight
150 kg
Operators (1)
Poland
