Z180 Chinese Autonomous Surface Vehicle (ASV)
Z180
Autonomous Surface Vehicle (ASV)
Other
Basic Information
Name
Z180 Chinese Autonomous Surface Vehicle (ASV)
Designation
Z180
Alternate Designation
Z180
Equipment Type
Autonomous Surface Vehicle (ASV)
Manufacturer
Chinese Defense Equipment Co.
Date of Introduction
2023
Description
The Z180 Chinese Autonomous Surface Vehicle (ASV) is aimed aim at performing underwater inspecting missions, it can pull the line array sonar to identify and inspect the submarine, UUV, etc. It could replace small arms stations, rescue equipment to perform reconnaissance, patrol, rescue missions.
Naval & Littoral Specifications
Beam
4.50 m
Draft
0.60 m
System
Alternative Designation
Z180
Type
Autonomous Surface Vehicle
Builder
Chinese Defense Equipment Co.
Crew
Autonomous
Working Mode
Autonomous Navigation, Remote-Control
Payload Capacity
1.5 tons
Communication Distance
1 km (remote-control unit); 20 km (base station)
Broadband Bandwidth
2 mbps (Private network)
Anti-Jamming Capability
Frequency Hopping communication anti-jamming
Discovery Distance
5 km
Identification Distance
2 km
Dimensions
Length
11.5 m
Height
3.7 m
Beam
4.5 m
Draft
0.6 m
Displacement, Full Load
9.0 tons
Propulsion System
Engine Name
INA
Engine Type
INA
Engine Power
INA
Communication Range
1 km (remote-control unit); 20 km (base station)
Maximum Speed
30 knots (55.56 km/h)
Endurance
1,111.2 km
Protection
Hull
INA
Countermeasures
INA
NBC Water Washdown System
INA
Image Sources
Details
Country of Origin
China
Category
Naval
Naval
Filter Label
Z
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
11.5 m
Width
4.5 m
Height
3.7 m
Weight
9000 kg
Operators (1)
China
