Leleka-100M2R Ukrainian Unmanned Aerial Vehicle (UAV)

Leleka-100M2R

Tactical Unmanned Aerial Vehicle (UAV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
Leleka-100M2R Ukrainian Unmanned Aerial Vehicle (UAV)
Designation
Leleka-100M2R
Alternate Designation
Leleka-100M2R
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Deviro
Date of Introduction
2019
Description

The Leleka-100M2R Ukrainian Unmanned Aerial Vehicle (UAV) is the most widely deployed modern reconnaissance system, performing a broad spectrum of combat missions and officially accepted into service with the Armed Forces of Ukraine since 2019. The Leleka reconnaissance system is equipped with two jam-resistant communication channels and can operate in adverse weather conditions. It features a daytime camera with 100× zoom and a state-of-the-art thermal imager for night operations. The system is fully autonomous and supports the crew throughout the mission — from reconnaissance and target detection to fire correction and objective assessment of results.

Air & Air Defense Specifications
Engine Electric
Cruise Speed 60.0 km/h
Range 340.0 km
Endurance 5.00 hrs
Service Ceiling 2000 m
Wingspan 3.29 m
System
Alternate Designation Leleka-100M2R
Type Unmanned Aerial Vehicle (UAV)
Manufacturer Deviro
Payload Capacity INA
Payload Daylight vision camera with 100x zoom (25× optical plus 4x digital), 360-degree azimuthal view, gyroscopically stabilized in two axis, target capture and automatic target tracking function, digital image stabilization system. Night vision camera - thermal module with 4× digital zoom, 360-degree azimuthal view, gyroscopically stabilized in two axis, target capture and automatic target tracking function, digital image stabilization system.
Flight Control System Autopilot with the full auto and navigation mode.
Video Transmission Channel Line-of-sight range of up to 55 km. Two-way digital channel with encryption AES 128 (256), MESH technology with the ability to control and transmit video simultaneously by several UAVs or relay a signal from one UAV to another UAV (for example, reconnaissance and strike UAVs).
Electronic Warare System Special anti-EW system that automatically detects means of GPS/GLONASS blocking, as well as navigation field spoofing, with automatic switching to the inertial navigation system. GNSS receiver with CRPA technology (interference-resistant GNSS receiver with EW countermeasure function).
Operating Temperature -35/+50 °C
Dimensions
Length 1.467 m
Height INA
Wingspan 3.285 m
Maximum Takeoff Weight 12.0 kg
Automotive
Engine Name INA
Engine Type Electric
Engine Power INA
Maximum Speed INA
Cruise Speed 60-70 km/h
Maximum Range 340 km
Service Ceiling 2,000 m
Endurance 5 hours
Wind Resitance Up to 20 M/S
Details
Country of Origin Ukraine
Category UAVs
Air > UAVs
Filter Label
L
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
1.47 m
Width
Height
Weight
12 kg
Operators (1)
Ukraine
