Centaur Class (Project 58181 Class) Ukrainian Assault Craft
Centaur Class
Fast Assault Craft
Other
Basic Information
Name
Centaur Class (Project 58181 Class) Ukrainian Assault Craft
Designation
Centaur Class
Alternate Designation
Centaur Class; Kentavr-Class; Project 58181 Class
Equipment Type
Fast Assault Craft
Manufacturer
Kuznya na Rybalskomu
Date of Introduction
2018
Description
The Centaur Class (Project 58181 Class) Ukrainian Assault Craft is a series of small armored assault craft built for the Ukrainian Navy. The first two vessels were laid down at the Kuznya na Rybalskomu in December 2016. The project was developed by State Research and Design Shipbuilding Center on the basis of the Gurza-M class artillery boats. Designed for carrying patrol service on rivers and coastal maritime areas, delivery and landing of marines.
Naval & Littoral Specifications
Crew
4
Beam
4.80 m
Draft
1.00 m
Variants
DSHK-1
Ukrainian Navy
DSHK-2
Ukrainian Navy
DSHK-3
Ukrainian Navy
DSHK-4
Ukrainian Navy
System
Alternative Designation
Centaur Class; Kentavr-Class; Project 58181 Class
Type
Fast Assault Craft
Builder
Kuznya na Rybalskomu, Ukraine
Crew
4 crew members + 26-28 equipped combat troops
Dimensions
Length
24.3 m
Beam
4.8 m
Draft
1.0 m
Displacement, Standard
47 tons
Propulsion System
Engine Name
INA
Engine Type
INA
Engine Power
INA
Maximum Range
500 nm @ 11 kts
Maximum Speed
35 knots
Weapon Systems
Combat Module Turret
Name
2 x BM-5M.01 Katran-M Turrets
Type
Remote-Controlled Deck Guns
Main Gun
Machine Gun
Caliber
12.7 mm
Maximum Rate of Fire
700 rds/min
Maximum Effective Range
2,500 m (Surface Targets)
Coaxial Weapon #1
Name
Grenade Launcher
Type
Coaxial
Caliber
40 mm
Cartridge
INA
Basic Load
INA
Rockets
Launcher
Modified MLRS
Rocket
S-8
Type
Unguided Artillery Rocket
Caliber
80 mm
Guidance
Unguided
Warhead
HEAT, HE-Frag and Smoke
Fire Control Systems
FCS Name
INA
Computerized FCS
Yes
Sensors and Communications
Navigation Radar
Yes
Optoelectronic monitoring system
Yes
Laser Emission Detection
Yes
Radio
HF/VHF/UHF/Satellite
Protection
Hull Armor
Armor placement around vital compartments (Engine Room, Troop Compartment, Control Room).
Countermeasures
INA
NBC Water Washdown System
Yes
Details
Country of Origin
Ukraine
Category
Naval
Naval
Filter Label
C
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
24.3 m
Width
4.8 m
Height
—
Weight
47000 kg
Operators (1)
Ukraine
