Sounder Class Norwegian Autonomous Surface Vehicle (ASV)
Sounder Class
Autonomous Surface Vehicle (ASV)
Other
Basic Information
Name
Sounder Class Norwegian Autonomous Surface Vehicle (ASV)
Designation
Sounder Class
Alternate Designation
Sounder Class
Equipment Type
Autonomous Surface Vehicle (ASV)
Manufacturer
Kongsberg
Date of Introduction
2020
Description
The Sounder Class Norwegian Autonomous Underwater Vehicle (AUV) supports quick and easy change of payload and is adaptable for both hull and bow-mounted systems. KONGSBERG’s K-MATE autonomy system provides safe navigation and control of the system, is capable of direct remote control, and supervised or autonomous operation. A robust and reliable propulsion system and hull design ensure safe sailing for up to 20 days.
Naval & Littoral Specifications
Beam
2.20 m
Draft
0.70 m
System
Alternative Designation
Sounder Class
Type
Autonomous Underwater Vehicle (AUV)
Builder
Kongsberg
Crew
Autonomous
Missions
AUV USBL position aiding; Seismic support; LBL/USBL calibration and position fix MULTIBEAM ECHO SOUNDER; Hydrographic surveys; Harbor surveys; Search
Control System
K-MATE autonomy engine for direct, supervised, and autonomous operation
Containers and Launch and Recovery System
The ability to transport the vessel in standard shipping containers, allowing for efficient deployment anywhere in the world.
Dimensions
Length
8.0 m
Height
2.3 m / 4.4 m (mast down/up)
Beam
2.2 m
Draft
0.7 m
Weight
4,200 kg
Propulsion System
Engine Name
Steyr, Model: INA
Engine Type
Diesel
Engine Power
125 hp
Propeller
Fixed pitch propeller
Maximum Range
INA
Maximum Speed
12 knots
Endurance
Up to 20 days @ 4 knots
Communications
Maritime Radio
Maritime Broadband Radio (MBR)
Iridium Satellite Communication System
Yes
Radar Systems
Navigation Radar
INA
Sonar Systems
Echo Sounder
1 x ES80/EK80 echosounder
Fishery Sonar
1 x SX95 fishery sonar for fish finding
Protection
Hull
The hull shape ensures smooth sailing through the water, eliminating aeration and minimizing drag. A slim bow and the stabilizing fins dampen roll and pitch movement while the three rudders provide exceptional manoeuvrability.
Countermeasures
No
NBC Water Washdown System
No
Image Sources
Notes
https://www.kongsberg.com/maritime/about-us/news-and-media/news-archive/2019/new-multipurpose-sounder-usv-from-kongsberg-unwrapped-at-ocean-business-2019/; https://www.hydro-international.com/content/news/sensors-robotics-emerges-as-new-entity-at-kongsberg; https://www.nationalfisherman.com/boats-gear/finders-keepers-new-trawl-technology-helps-fleets-fish-smarter-and-managers-track-biomass-despite-covid-disruptions; https://www.nationalfisherman.com/national-international/robocatch-simrad-builds-unmanned-surface-sounders;
Details
Country of Origin
Norway
Category
Naval
Naval
Filter Label
S
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
8 m
Width
2.2 m
Height
2.3 m
Weight
4200 kg
Operators (1)
Norway
