Gwanggaeto the Great Class (KDX-I Class) South Korean Destroyer
Gwanggaeto the Great Class
Destroyer
Other
Basic Information
Name
Gwanggaeto the Great Class (KDX-I Class) South Korean Destroyer
Designation
Gwanggaeto the Great Class
Alternate Designation
Gwanggaeto the Great Class; KDX-I
Equipment Type
Destroyer
Manufacturer
—
Date of Introduction
1998
Description
The Gwanggaeto the Great-class destroyers, often called KDX-I, are destroyers but are classified by some as frigates, operated by the Republic of Korea Navy. It was the first phase of ROKN's KDX program, in moving the ROK Navy from a coastal defense force to a blue-water navy.
Naval & Littoral Specifications
Crew
185
Beam
14.20 m
Draft
4.30 m
Variants
ROKS Gwanggaeto the Great
Commissioned: 1996
Status: Active
ROKS Eulji Mundeok
Commissioned: 1997
Status: Active
ROKS Yang Man-chun
Commissioned: 2000
Status: Active
System
Alternative Designation
Gwanggaeto the Great Class; KDX-I
Type
Destroyer
Builder
Daewoo Heavy Industries Co.
Crew
185 (15 Off. + 155 Enl.)
Dimensions
Length
135.40
Beam
14.20 m
Draft
4.30 m
Displacement, Standard
3,181 tons
Displacement, Full Load
3,855 tons
Propulsion System
Gas Turbine Engine
2 x General Electric LM-2500 gas turbines
Diesel Engine Name
2 x MTU type 20V956 TB92 diesels
Diesel Engine Power
59,000 total bhp
Maximum Speed
30 knots (56 km/h; 35 mph)
Range
4,500 nmi (8,300 km; 5,200 mi) at 18 kn (33 km/h; 21 mph)
Gun Weapon Systems
Gun Weapon System #1
Name
1 x OTO Melara 127/64
Type
Naval Gun
Caliber
127 mm
Quantity
1
Crew
Remote Controlled
Elevation
−15°/+83°
Traverse
360°
speed: 40°/s
Rate of Fire
40 rounds/min
Effective Range
100 km with guided VULCANO ammunition
Feed System
Magazine capacity:
66 ready rounds
Gun Weapon Systems #1 Ammunition
Type
Rifle
Caliber
127 mm
INA
INA
Basic Load
INA
Gun Weapon System #2
Name
2 x Goalkeeper CIWS
Type
Close-in-Weapon System (CIWS)
Caliber
30 mm
Quantity
2
Crew
Automated, with human oversight
Barrels
7-barrel (progressive RH parabolic twist, 14 grooves)
Elevation
+85 to −25 degrees at 80 degree/s
Traverse
360 deg
Rate of Fire
70 rounds/second (4,200 rounds/minute)
Muzzle Velocity
1,109 m/s
Effective Firing Range
350 to between 1,500 and 2,000 m
Gun Weapon Systems #2 Ammunition
Type
Rifle
Caliber
30 mm
Shell
30×173mm TP, HEI, MPDS, or FMPDS
Basic Load
INA
Missile Weapon System
Launcher
Name
1 x 16-cell Mark 48 VLS launcher
Missile
Name
RIM Sea-7 Sparrow
Type
Surface-to-Air Missile
Speed
Mach 2.5
Maximum Range
14.8 km
Torpedo System
Launcher
2 x triple 324-mm ASW torpedo tubes
Torpedo Name
INA
Basic Load
46
Fire Control Systems
FCS Name
2 x Thales Goalkeeper Fire Control System
Computerized FCS
Yes
Battle Management System
Yes
Radar Systems
Air Search Radar
1 x Thales MW-08 air search
Surface Search Radar
1 x ISC-Cardion AN/SPS-55M surface search
Navigation Radar
1 x Daewoo DTR-92 navigation
Sonar Systems
Active and Passive Sonar
1 STN Atlas Elektronik DSQS-21BZ hull-mounted active/passive/search/attack
Towed Linear Passive Sonar
1 x Thales towed linear passive hydrophone array of undisclosed type
Aircraft Facilities
Aircraft
2 x Super Lynx [carries Sea Skua ASM missiles or U.S. Mark 46, Mod. 5 ASW torpedoes].
Protection
Active Protection System
2 x 330-340 round Matra-Defense Dagaie Mark 2 decoy rocket launching system
Torpedo Decoy
1 x U.S. AN/SLQ-25 NIXIE towed acoustic torpedo decoy system.
EW
1 x ArgoSystems APECS-II/AR-700 intercept/jammer suite
NBC Water Washdown System
Yes
Image Sources
Details
Country of Origin
South Korea
Category
Naval
Naval
Filter Label
G
Classification
Domain
Naval & Littoral
Equipment Status
Active
Dimensions
Length
135.4 m
Width
—
Height
—
Weight
—
Operators (1)
South Korea
