Unitree GO1 Pro Chinese Unmanned Ground Vehicle (UGV)
Unitree GO1 Pro
Unmanned Ground Vehicle (UGV)
Other
Basic Information
Name
Unitree GO1 Pro Chinese Unmanned Ground Vehicle (UGV)
Designation
Unitree GO1 Pro
Alternate Designation
Unitree GO1 Pro
Equipment Type
Unmanned Ground Vehicle (UGV)
Manufacturer
Unitree Robotics
Date of Introduction
2021
Description
Unitree Go1 series consists of quadruped robots for the research & development of autonomous systems in the fields of robot-human interaction (HRI), SLAM & transportation. Due to the four legs, as well as the 12DOF, this robot can handle a variety of different terrains. The Go1 is Unitree’s latest device and comes with a perfected drive & power management system, which enables a speed (depending on the version) of up to 3.7m/s or 11.88km/h with an operating time of up to 2.5 hours.
Ground Specifications
Engine
Battery
Max Speed
17.0 km/h
Variants
Go1 Air
The differences are mainly the processors and sensor systems, the Air and Pro variant works, depending on the model, with one or 3x “4*1.43GHz 128Core 0.5T” processor as well as with 1 or 5 Super Sensor System. Both variants are equipped with 3 ultrasonic sensors.
Go1 Pro
The differences are mainly the processors and sensor systems, the Air and Pro variant works, depending on the model, with one or 3x “4*1.43GHz 128Core 0.5T” processor as well as with 1 or 5 Super Sensor System. Both variants are equipped with 3 ultrasonic sensors.
Go 1 Edu
The Go 1 Edu variant has up to 3 nano processors, 5x super sensor systems, and 4 ultrasonic sensors.
System
Alternate Designation
Unitree GO1 Pro
Type
Robotic Dog Unmanned Ground Vehicle (UGV)
Manufacturer
Unitree Robitics
Crew
Unmanned
Controller
1 ea
Intelligent Side Follow System
Adopt Patented Wireless Vector Positioning and Control Technology
• Robot dog can walk alongside its owner and not only follow
• The human-machine interaction is both harmonious and safe
Super Sensory System
• Full View Coverage
• 5 Sets Fish-Eye Stereo Depth Cameras + AI Post-processing + 3 Sets of Hypersonic Sensors
• Lens Angle = 150 x 170°
AI
16 core CPU + GPU (384Core, 1.5TFLOPS)
Payload Capacity
3 kg
Dimensions
Length, Folded
0.58 m
Width, Folded
0.29 m
Height, Folded
0.22 m
Weight
12 kg
Automotive
Engine Name
INA
Engine Type
Battery
Engine Power
INA
Maximum Speed
17 km/h
Endurance
INA
Details
Country of Origin
China
Category
Unmanned Ground Vehicles (UGV)
Land > Unmanned Ground Vehicles (UGV)
Filter Label
U
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
—
Width
—
Height
—
Weight
12 kg
Operators (1)
China
