3M-54 Kalibr (SS-N-27 Sizzler) Russian Short-Range Cruise Missile
3M-54 Kalibr
Cruise Missile
Other
Basic Information
Name
3M-54 Kalibr (SS-N-27 Sizzler) Russian Short-Range Cruise Missile
Designation
3M-54 Kalibr
Alternate Designation
3M-54 Kalibr; SS-N-27 Sizzler
Equipment Type
Cruise Missile
Manufacturer
Novator Experimental Design Bureau
Date of Introduction
1994
Description
The 3M-54 Kalibr (SS-N-27 Sizzler) Russian Short-Range Cruise Missile is equipped with a three-stage solid-propellant turbojet engine.
Variants
3M14K (SS-N-30A)
An inertial guidance land-attack variant deployed by the Russian Navy. The submarine-launched weapon has a basic length of 6.2 m (20 ft), with a 450 kg (990 lb) warhead. Its range is 2,500 km (1,600 mi), allowing the Russian Navy to strike targets throughout central Western Europe (including all of the UK, northern France including Paris, and most of Germany) from beyond the GIUK gap. Its subsonic terminal speed is Mach 0.8.
3M14T
The inertial guidance land-attack variant is deployed by the Russian Navy. A surface ship with VLS launched a missile, with a thrust vectoring booster, its basic length is 8.9 m (29 ft), and its warhead weight and other performance are the same as the 3M14K.
3M-14TE
An inertially guided, ship-launched, land-attack variant with VLS and a thrust vectoring booster. Its basic length is 8.9 m (29 ft), and its warhead weight and other performances are the same as the 3M-14E. Its subsonic terminal speed is 0.8 mach, with a range of 300 km (190 mi) at supersonic speed.
91RE1
A submarine-launched anti-submarine variant, it consists of two stages, one solid booster with four grid fins and one anti-submarine light torpedo. Its basic length is 7.65 m (25.1 ft), it has a range of 50 km (31 mi). It can reach supersonic speed. The torpedo has warhead weight of 76 kg (168 lb). It is similar to the American ASROC/SUBROC missile/torpedo system. It follows a ballistic path on the surface, with a speed of Mach 2.5.
91RTE2
The surface ship, VLS launched an anti-submarine variant; it consists of three stages, one booster with thrust vector nozzle, one conventional booster, and one anti-submarine light torpedo. Its basic length is 8.9 m (29 ft), with a range of 40 km (25 mi) at supersonic speed. The torpedo has warhead weight of 76 kg (168 lb). The lightest of all variants, with a launch weight of 1,300 kg (2,900 lb). Speed is Mach 2.
Club-M
Land-based anti-ship missile for coastal defense. Range 300 km, includes supersonic terminal sprint phase.
System
Alternate Designation
3M-54 Kalibr; SS-N-27 Sizzler
Type
Short-Range Cruise Missile
Manufacturer
Novator Experimental Design Bureau
Guidance System
Inertial guidance system
Effective Range
220 km
Circular Error Probability
3 m
Basing
Submarine, Ship, Aircraft, Ground
Dimensions
Length
8.22 m
Missile Weight
1,920 kg
Diameter
0.533 m
Fin Span
INA
Propulsion Characteristics
Engine
Turbojet (3M54 is three stage, 3M54M1 is two stage)
Propellant
Solid
Speed
Mach 0.8 - Mach 2.9
Flight Ceiling
1,000 m
Flight Altitude
50-150 m AGL
Payload
Type
Single warhead
Warhead Type
Conventional or Nuclear
Warhead Weight
200 kg HE
Nuclear Yield
INA
Conventional Warhead Weight
400-500 kg
Conventional Warheads Available
HE
Details
Country of Origin
Russia
Category
Short-Range Cruise Missiles (SRCM) (Less than 600 km)
Air > Short-Range Cruise Missiles (SRCM) (Less than 600 km)
Filter Label
3
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
8.22 m
Width
0.53 m
Height
—
Weight
—
Operators (7)
Russia
China
India
Iran
Algeria
Venezuela
Vietnam
