Mugin-6 Chinese Unmanned Aerial Vehicle (UAV)
Mugin-6 Pro
VTOL Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Mugin-6 Chinese Unmanned Aerial Vehicle (UAV)
Designation
Mugin-6 Pro
Alternate Designation
Mugin-6 Pro
Equipment Type
VTOL Unmanned Aerial Vehicle (UAV)
Manufacturer
Mugin UAV
Date of Introduction
2021
Description
The Mugin-6 Chinese Unmanned Aerial Vehicle (UAV) is designed based on the Mugin 4450 VTOL with an extended wingspan of 6000mm, in hope of reaching a longer flight time of 10 hours.
Air & Air Defense Specifications
Engine
Gasoline
Max Speed
129.0 km/h
Cruise Speed
115.0 km/h
Range
300.0 km
Endurance
5.00 hrs
Wingspan
6000.00 m
Payload Capacity
20 kg
System
Alternate Designation
Mugin-6 Pro
Type
Vertical Take-Off and Landing (VTOL) Unmanned Aerial Vehicle (UAV)
Manufacturer
Mugin UAV
Autonomy
Semi-Autonomous
Crew
Unmanned
Payload Capacity
20 kg
Launching System
Vertical Take-Off and Landing (VTOL)
Recovery System
Vertical Take-Off and Landing (VTOL)
Dimensions
Length
3,500 mm
Wingspan
6,000 mm
Width (Fuselage)
375 mm
Height
INA
Empty Weight
34.2 kg
Maximum Takeoff Weight
110 kg
Automotive
Engine Name
DLA 232cc Engine w/ EFI, Starter & Alternator
Engine Type
Gas
Engine Power
INA
Fuel Capacity
28 liters
Maximum Speed
129 km/h
Cruise Speed
115 km/h
Stall Speed
86 km/h
Service Ceiling
INA
Maximum Range
300 km depending on payload
Endurance
5 - 10 hours
Image Sources
Notes
https://www.facebook.com/muginuav/posts/the-new-mugin-6000-vtol-is-here-more-details-are-available-soon-muginuavcom/888731075037607/; https://www.facebook.com/muginuav/posts/the-new-mugin-6000-vtol-is-here-more-details-are-available-soon-muginuavcom/888731075037607/; https://www.airmobi.com/product/skyeye-5000-vtol-uav-platform/;
Details
Country of Origin
China
Category
UAVs
Air > UAVs
Filter Label
M
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
3.5 m
Width
—
Height
—
Weight
110 kg
Operators (1)
China
