BOXER LANCE German Infantry Fighting Vehicle (IFV)

BOXER LANCE

Infantry Fighting Vehicle (IFV)
Spotted an error? Sign in to suggest an edit.
Basic Information
Name
BOXER LANCE German Infantry Fighting Vehicle (IFV)
Designation
BOXER LANCE
Alternate Designation
BOXER LANCE
Equipment Type
Infantry Fighting Vehicle (IFV)
Manufacturer
Rheinmetall
Date of Introduction
2024
Description

The BOXER LANCE German Infantry Fighting Vehicle (IFV) is a modern, armored 8x8 vehicle used by armed forces worldwide. It provides enhanced protection for the crew while delivering a high level of firepower and mobility. The Boxer Lance features a manned Lance2 turret system that includes a highly effective 30mm MK30-2/ABM cannon, which has anti-tank capabilities along with secondary armament. The modular turret technology complements the vehicle's modular design, allowing for versatile configurations that can meet the needs of different troop types, such as a heavy infantry weapon carrier or a wheeled infantry fighting vehicle with dismount capability. **Technical Superiority:** The Boxer Lance is equipped with state-of-the-art weapon systems, sensors, and optronics. The proven 30mm MK30-2/ABM main weapon provides high accuracy and effective firepower against air and ground targets at ranges of up to 3,000 meters. The integrated Anti-Tank Guided Missile (ATGM) system further enhances its anti-armor capabilities. **Robustness:** The vehicle is designed to maintain operational capability for both crew and systems through a multi-layer protective structure that separates the crew from weapons and ammunition. Additionally, turret operators can reload the main and secondary coaxial weapons while remaining under armor. The combined manual/electric backup mode allows for control of the Lance2 turret even if the primary power source fails. **Logistical Supply Capability:** The Boxer Lance offers ample storage space, both inside and outside, for essential equipment and ammunition. The turret is compatible with 30mm, 7.62mm, and 12.7mm NATO standard ammunition. Over 400 Lance2 systems will be in service with various nations, including Australia, Hungary, and Germany. These systems share logistical compatibility, ensuring constant availability of spare parts. **Scalability:** The Boxer Lance boasts significant growth potential thanks to its General Vehicle Architecture (GVA) core structure. This design allows for easy integration of new mission systems and effectors, such as C-UAV radar reconnaissance, loitering munitions, and AI-assisted acceleration of the OODA (Observe, Orient, Decide, Act) loop, without compromising the basic turret architecture. A range of mission-ready data interfaces inside and outside the turret supports these capabilities.

Ground Specifications
Crew 3
Mobility Type Wheeled (8x8)
Main Weapon 30mm MK30-2/ABM cannon
Engine Diesel (815 hp)
NBC Protection Yes
Max Speed 100.0 km/h
Range 1100.0 km
System
Alternative Designation BOXER LANCE
Type Infantry Fighting Vehicle (IFV)
Manufacturer Rheinmetall
Configuration 8x8
Crew 3 ea
Passenger Capacity 8 ea
Dimensions
Length 8.87 m
Width 2.99 m
Height 3.66 m
Weight, Combat 39,500 kg
Automotive
Engine Name MTU 8V199 V8
Engine Type Diesel
Engine Power 815 hp
Maximum Range 1,100 km
Maximum Land Speed 100 km/h
Amphibious No
Gradient 60%
Side Slope 40 deg
Vertical Step 0.70 m
Trench 2.0 m
Main Weapon System
Turret Lance 2 turret
Type 1 x Rheinmetall MK30-2/ABM 30x173mm
Targeting Sights Rheinmetall SEOSS2 with 5km day & infrared range; 6x zoom
Elevation –10° to +45°
Traverse 360°
Ammunition APFSDS-T, KETF (Air Burst), Training ammunition
Basic Load 252 rounds total; double belt feed
Coaxial Weapon System
Type 1 x FN Herstal MAG58 or other 7.62x51mm
Basic Load 625 rounds
Anti-Tank Guided Missile (ATGM)
Type Rheinmetall Twin SPIKE LR/LR2 launcher
Protection
Hull Armor different protection levels possible
Turret Armor INA
Applique Armor INA
Situational Awareness System 360° day and infrared range, acoustic platform for vehicles, laser warner
NBC Protection Yes
Smoke Equipment Rheinmetall ROSY with 180° coverage, two salvos
Details
Country of Origin Germany
Category Land
Land
Filter Label
B
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
8.87 m
Width
2.99 m
Height
3.66 m
Weight
39500 kg
Operators (3)
Germany
Australia
Hungary
