R-187-P1E AZART Russian Handheld Tactical Radio
R-187-P1E
Tactical, Handheld, Software-defined Radio (SDR)
Other
Basic Information
Name
R-187-P1E AZART Russian Handheld Tactical Radio
Designation
R-187-P1E
Alternate Designation
R-187-P1E Tactical Radio, Squad/Platoon Tactical Radio
Equipment Type
Tactical, Handheld, Software-defined Radio (SDR)
Manufacturer
NPO Angstrem
Date of Introduction
2014
Description
The R-187-P1E AZART is a multi-mode tactical team radio with programmable security architecture and provides voice and data communication in VHF and UHF frequency ranges. The radio is a dual channel wideband transceiver that can be integrated with the Terrestrial Trunked Radio (TETRA) communication system allowing it to communicate with external parties in TETRA networks. The R-187-P1E is a software defined radio (SDR) and has frequency hopping capability. It also has embedded GLONASS and GPS capabilities, and can exchange user location information.
Variants
R-187VE
Next generation radio in the AZART family of handheld tactical radios. The R-187VE is planned to be compatible with the R-187-P1E and provides multi-band High Frequency (HF) communications across a 1.5 megahertz/MHz to 30MHz waveband, Very High Frequency (VHF) communications across a waveband of 30MHz to 180MHz and three Ultra High Frequency (UHF) waveband options of 220MHz to 470MHz, 550MHz to 1.25 gigahertz/GHz and 1.65GHz to 2.5GHz. All of these wavebands are expected to have one kilohertz channel spacing and power output levels between ten watts/W up to 100W, according to the waveband. Similarly data rates differ, with 9.6 kilobits-per-second (kbps) achievable across HF, 255kbps achievable using VHF with between two megabits-per-second (mbps) and 32mbps achievable using UHF. The company’s official literature states that the radio can achieve a range of 500 kilometers/km (310.7 miles) in HF, and between five kilometers (3.1 miles) up to 20km (12.4 miles) using V/UHF. The R-187VE is also expected to perform100 hops-per-second, although rates of up to 20,000 hops-per-second are achievable with V/UHF, and will use proprietary Russian Army waveforms. Other waveforms can be ported into the transceiver including simplex and duplex voice communications, high speed data, video, navigational information and that the radio can support a network hosting up to 16,000 subscribers.
System
Alternate Designation
R-187-P1E Tactical Radio, Squad/Platoon Tactical Radio
Type
Tactical, Handheld, Software-defined Radio (SDR)
Family
Ratnik Future Soldier System
Manufacturer
NPO Angstrem
Digital
Yes
Dimensions
Height
192 mm (without antenna)
Width
65 mm
Diameter
37 mm
Weight
500 g (with battery)
Performance
Waveform
Proprietary (Russian Army)
Frequency Range
27 - 530 Mhz
Operational Range
5 - 20 Km
Number of Channels
2
Channel Bandwidth (VHF)
1, 6.25 or 8.33 kHz
Channel Bandwidth (UHF)
25 kHz
Data Rate
256 Kbps (reduced to 28 Kbps in frequency hop mode)
Battery
Li-ion battery (2 types: 6 Ah and 12 Ah)
Battery Life
12 hrs
Satellite Receiver
Yes, using GLONASS and GPS
Extended Network
Yes, compatible with TETRA (Terrestrial Trunked Radio) standard using Time Division Multiple Access (TDMA).
Protection
Encryption
Yes
Frequency Hop
Yes (20,000 hops/s)
ECCM Mode
Yes
Image Sources
Details
Country of Origin
Russia
Category
Multiband Radios
Land > Communication Equipment > Multiband Radios
Filter Label
R
Classification
Domain
Ground
Equipment Status
Active
Dimensions
Length
—
Width
0.07 m
Height
0.19 m
Weight
0.5 kg
Operators (1)
Russia
