Bravo Plus Pakistani Unmanned Aerial Vehicle (UAV)
Bravo Plus
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Bravo Plus Pakistani Unmanned Aerial Vehicle (UAV)
Designation
Bravo Plus
Alternate Designation
Bravo Plus
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Satuma
Date of Introduction
2017
Description
The Bravo Plus Pakistani Unmanned Aerial Vehicle (UAV) can be used in Tactical Range reconnaissance, surveillance, damage assessment and various civil applications.
Air & Air Defense Specifications
Engine
4 cylinder, 2 stroke Gasoline Engine (38 hp)
Max Speed
130.0 km/h
Endurance
5.00 hrs
Service Ceiling
3 m
Wingspan
4.92 m
Payload Capacity
25 kg
System
Alternate Designation
Bravo Plus
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
Satuma
Autonomy
Guidance/Tracking: Remote control/pre-programmed autonomous navigation
Crew
Unmanned
Ground Control Station
2 x console, truck mounted
Payload Capacity
25 kg
Reconnaissance Equipment
INA
Launching System
Wheeled
Recovery System
Wheeled
Dimensions
Length
4.27 m
Wingspan
4.92 m
Height
INA
Maximum Takeoff Weight
145 kg
Automotive
Engine Name
INA
Engine Type
4 cylinder, 2 stroke Gasoline Engine
Engine Power
38 hp
Electrical Power
28V, 900W
Maximum Speed
130 km/h
Cruising Speed
INA
Service Ceiling
3 km
Maximum Distance
100 km
Endurance
5 hours
Image Sources
Notes
https://www.facebook.com/pakistanidefence/photos/a.264394517662/10151335568567663/?type=3; https://www.linkedin.com/posts/thamer-alshammari-pmp-2935b2123_chinas-new-stealth-drone-may-revolutionize-activity-7029815326536011776-kE_U; https://www.linkedin.com/posts/thamer-alshammari-pmp-2935b2123_chinas-new-stealth-drone-may-revolutionize-activity-7029815326536011776-kE_U; https://www.satuma.com.pk/Trainer%20UAV%27s.php;
Details
Country of Origin
Pakistan
Category
UAVs
Air > UAVs
Filter Label
B
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
4.27 m
Width
—
Height
—
Weight
145 kg
Operators (1)
Pakistan
