Sentry American Unmanned Aerial Vehicle (UAV)
Sentry
Tactical Unmanned Aerial Vehicle (UAV)
Other
Basic Information
Name
Sentry American Unmanned Aerial Vehicle (UAV)
Designation
Sentry
Alternate Designation
Sentry
Equipment Type
Tactical Unmanned Aerial Vehicle (UAV)
Manufacturer
Hoverfly
Date of Introduction
2024
Description
The Sentry American Unmanned Aerial Vehicle (UAV) is a leading national provider of federal defense, security, and public safety drones. The SENTRY is designed to meet IP54 and MIL-STD-810 standards and is a military-grade tether-powered UAS ready for any mission. Our tether-powered system provides infinite power and continuous operation. It features enterprise multi-site control with Smart Command software by Hexagon. The SENTRY requires minimal training, and no piloting is needed. It also features a PTZ Hi-Def camera with 10x optical zoom, built-in-lead, flank, and follow “on the move” technology.
Air & Air Defense Specifications
Engine
Supplied by tether with backup battery
Range
60.0 km
Service Ceiling
60 m
Payload Capacity
0 kg
System
Alternate Designation
Sentry
Type
Unmanned Aerial Vehicle (UAV)
Manufacturer
Hoverfly
Construction
Composite and carbon
Payload Capacity
0.81 kg
Payloads
Qualified payloads include Silvus, Trellisware, Persistent Systems, L3 Harris, Viasat, goTenna, multiple sensors, cameras, and others.
Communication
Secure data/video over tether
SDK Integration
Hoverfly’s Software Development Kit (SDK) allows Hoverfly and its sensors to be controlled over various networks or the internet for multiple fused sources in a Common Operating Picture (COP). It also enables seamless integration with existing security and video management systems with libraries for .NET, C++, and more coming soon. Our SDK provides three levels of access to the Hoverfly system: full control, payload-only control, and telemetry monitoring.
Environmental
IP54*, MIL-STD-810G*
Operating Temperature
.20C to +55C
Launch and Recovery
Launch and recover without optical sensors for precise landing in all-weather environments.
Dimensions
Length
50 cm
Width
50 cm
Height
27 cm
Weight, without Payload
2.3 kg
Automotive
Engine Name
INA
Engine Type
Supplied by tether with backup battery
Engine Power
INA
Maximum Speed
INA
Maximum Range
60 m tether
Service Ceiling
60 m tether
Endurance
INA
Image Sources
Details
Country of Origin
United States
Category
UAVs
Air > UAVs
Filter Label
S
Classification
Domain
Air & Air Defense
Equipment Status
Active
Dimensions
Length
0.5 m
Width
0.5 m
Height
0.27 m
Weight
2.3 kg
Operators (1)
United States
